Airtac SAID200 Double Rod Cylinder SAID200X125S
$534.82
Regular price
$542.32
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAID200X125S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. ISO15552 (formerly ISO6431) standard cylinder
2. Asymmetric bidirectional sealing structure for piston sealing with compact dimensions and integrated oil reservoir functionality;
3. Cross-shaped aluminum tube construction without tie rods, offering superior corrosion resistance; External sensor mounting grooves enable quick and convenient sensor installation;
4. Smooth adjustable cushioning mechanism for stable operation;
5. Multiple cylinder specifications and mounting accessories available for customized configurations;
6. High-temperature resistant sealing materials ensure operational temperature range of 0-150℃.
Category: Double Rod Cylinder | Brand: AIRTAC | Series: SAID200
Installation guidelines:
Ensure both rod ends are properly aligned within ±0.2mm parallelism tolerance.
Use locking nuts (included) with 15-20Nm torque for rod end fittings.
Lubricate with ISO VG32 hydraulic oil during initial installation.
2. Asymmetric bidirectional sealing structure for piston sealing with compact dimensions and integrated oil reservoir functionality;
3. Cross-shaped aluminum tube construction without tie rods, offering superior corrosion resistance; External sensor mounting grooves enable quick and convenient sensor installation;
4. Smooth adjustable cushioning mechanism for stable operation;
5. Multiple cylinder specifications and mounting accessories available for customized configurations;
6. High-temperature resistant sealing materials ensure operational temperature range of 0-150℃.
Category: Double Rod Cylinder | Brand: AIRTAC | Series: SAID200
AirTAC SAID200X125S Dual Rod Cylinder Specifications
- Model: SAID200X125S
- Type: ISO 15552 compliant dual rod cylinder
- Bore size: 20mm (φ20)
- Stroke: 125mm (adjustable cushion range: 5-25mm)
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable pneumatic cushion
- Mounting style: Front flange (MF1) / Rear flange (MF2) optional
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Piston rod thread: M10x1.25 (both ends)
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal material: NBR (standard) / FKM (fluorine rubber) optional
- Weight: 2.8kg (with standard accessories)
- Dimensions: 250mm(L) × 80mm(W) × 80mm(H) (at mid-stroke position)
- Rod deflection: ≤0.3mm under max load
- Max piston speed: 500-700 mm/s (with cushion)
Precision-engineered dual rod cylinder featuring symmetrical force transmission and enhanced lateral load capacity. The twin-rod design eliminates rotational torque during operation, making it ideal for applications requiring parallel motion accuracy. Equipped with an adjustable air cushion system that reduces end-impact noise to ≤70dB(A).
Typical Applications:
- Precision alignment in semiconductor wafer handling systems
- Simultaneous clamping mechanisms in CNC fixture tables
- Vertical lift systems with counterbalance requirements
- Packaging machinery with synchronized gripper movements
- Automotive welding jigs requiring dual-sided force application
Installation guidelines:
Ensure both rod ends are properly aligned within ±0.2mm parallelism tolerance.
Use locking nuts (included) with 15-20Nm torque for rod end fittings.
Lubricate with ISO VG32 hydraulic oil during initial installation.
Critical parameters:
- Max lateral load: 45N at cylinder center
- Max moment load: 8.5N·m
- Air quality requirement: ISO 8573-1 class 3.4.2
- Re-lubrication interval: 500km stroke distance
| Property | Property Value |
|---|---|
| sku | SAID200X125S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Cushion Stroke | <50mm> |
| Bore Diameter | <200mm> |
| Stroke | 125mm |
