Airtac SAID200 Double Rod Cylinder SAID200X135S
2. Asymmetric bidirectional sealing structure for piston sealing with compact dimensions and integrated oil reservoir functionality;
3. Cross-shaped aluminum tube construction without tie rods, offering superior corrosion resistance; External sensor mounting grooves enable quick and convenient sensor installation;
4. Smooth adjustable cushioning mechanism for stable operation;
5. Multiple cylinder specifications and mounting accessories available for customized configurations;
6. High-temperature resistant sealing materials ensure operational temperature range of 0-150℃.
Category: Double Rod Cylinder | Brand: AIRTAC | Series: SAID200
AirTAC SAID200X135S Double Rod Cylinder Specifications
- Model: SAID200X135S
- Type: Double rod cylinder (ISO 6432 standard)
- Bore size: Ø20mm
- Stroke: 135mm
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Adjustable rubber buffer (both ends)
- Piston rod thread: M10×1.25 (both ends)
- Mounting type: Basic (no built-in mounts)
- Operating temperature: -20℃ to 80℃
- Seal material: NBR (standard)/PU (optional)
- Port size: M5×0.8 (G1/8 optional)
- Weight: 1.4kg (dry)/1.6kg (with grease)
- Dimensions: 226mm(L) × 40mm(W) × 40mm(H)
- Rod diameter: Ø8mm (chrome-plated)
- Max thrust: 314N @ 1.0MPa
- Lubrication: Required (ISO VG32 hydraulic oil)
Precision double-rod pneumatic cylinder featuring twin guide rods for enhanced moment resistance and alignment stability. The symmetrical design minimizes lateral deflection during operation, making it ideal for applications requiring precise linear motion with side load resistance. Features corrosion-resistant aluminum alloy body and integrated wear bands for smooth operation.
- Precision positioning in semiconductor handling equipment
- Vertical lifting mechanisms in packaging lines
- Clamping fixtures for CNC machine tooling
- Automated inspection station actuators
- Material transfer systems with guided tooling plates
Installation note:
Requires parallel alignment within 0.05mm/m tolerance. Use C-shaped mounting brackets (sold separately) for secure fixation.
Lubricate through air port during initial installation (30-40 drops ISO VG32 oil). Avoid side load exceeding 35N.
| Property | Property Value |
|---|---|
| sku | SAID200X135S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Cushion Stroke | <50mm> |
| Bore Diameter | <200mm> |
| Stroke | 135mm |
