Airtac SAID32 Double Rod Cylinder SAID32X115S
2、Profiled bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir;
3、Cross-shaped aluminum tubing design eliminates tie rods, enhancing corrosion resistance. External sensor mounting grooves enable quick and convenient installation;
4、Smooth cushioning adjustment mechanism;
5、Available in multiple configurations with compatible mounting accessories;
6、High-temperature resistant sealing materials support operating range of 0–150°C.
Category: Twin Shaft Cylinder , Brand: AirTAC , Series: SAID32
AirTAC SAID32X115S Dual Rod Cylinder Specifications
- Model: SAID32X115S
- Type: Double rod compact cylinder (ISO 6432 compliant)
- Bore size: 32mm
- Stroke: 115mm (standard), customizable up to 500mm
- Operating pressure: 0.1–0.9 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion at both ends
- Port size: M5x0.8 (G1/8 optional)
- Mounting: Basic type (no foot mount), with axial mounting holes
- Rod material: Hard chrome-plated steel
- Tube material: Aluminum alloy (black anodized)
- Seal material: NBR (standard), optional FKM for high temp
- Weight: 1.3kg (without accessories)
- Dimensions: 194mm(L) x 40mm(W) x 40mm(H)
- Rod diameter: 12mm (dual rods)
- Protection rating: IP40 (IP67 with optional wiper seal)
- Theoretical force: 231N at 0.7MPa (push/pull)
Precision dual-rod cylinder designed for applications requiring exceptional guidance accuracy and side load resistance. Features symmetrical force transmission and anti-rotation stability, with optional magnetic piston for position sensing. Optimized for high duty cycles in compact installations.
- Precision alignment in PCB assembly fixtures
- Vertical lifting mechanisms in packaging lines
- Clamping devices for CNC machining centers
- Material transfer systems with guided tooling plates
- Automated test equipment requiring dual-side force
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain parallel alignment of dual rods during mounting - maximum allowable angular misalignment: ±0.5°.
Use locknuts (included) for vibration-prone environments.
| Property | Property Value |
|---|---|
| sku | SAID32X115S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Stroke | 27mm |
| Bore Diameter | <32 mm> |
| Stroke | 115mm |
