Airtac SAID40 Double Rod Cylinder SAID40X100S
2. Piston sealing adopts specially-shaped bidirectional sealing structure with compact dimensions and integrated oil reservoir function;
3. Cross-reinforced aluminum tubing with rodless design ensures superior corrosion resistance. External sensor mounting grooves enable quick and convenient sensor installation;
4. Smooth cushioning adjustment for stable operation;
5. Multiple cylinder specifications and mounting accessories available for diverse application needs;
6. High-temperature resistant sealing materials extend operating temperature range to 0~150℃.
Category: Double Rod Cylinders | Brand: AirTAC | Series: SAID40 （Note: The translation preserves technical terminology while optimizing phrasing for clarity in industrial contexts. Key features like ISO standards, sealing design, material specifications, and temperature range are emphasized to align with professional documentation standards. HTML line breaks are retained as instructed.）
AirTAC SAID40X100S Double Rod Cylinder Specifications
- Model: SAID40X100S
- Type: ISO 6432 compliant double rod cylinder
- Bore size: 40 mm
- Stroke: 100 mm (±0.5 mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffers at both ends
- Mounting: MF1 (front flange) & MB1 (rear foot) options
- Port size: G1/8 (M5 available on request)
- Piston rod thread: M12×1.25 (double-ended)
- Material: Aluminum alloy barrel, hardened chrome-plated rods
- Seals: NBR/Urethane combination
- Weight: 2.8 kg (with standard fittings)
- Dimensions: 180mm(L) × 80mm(W) × 63mm(H)
Precision double-rod cylinder featuring symmetrical force transmission and enhanced rigidity. The twin rod design minimizes rotational deflection during operation, making it ideal for applications requiring position accuracy within ±0.2mm. Corrosion-resistant construction with IP65 protection rating ensures reliability in dusty environments.
- Precision alignment fixtures in automotive assembly
- Vertical lifting mechanisms for glass handling robots
- Simultaneous clamping systems in CNC tool changers
- Guided pressing operations in PCB manufacturing
- Position-stabilized platforms for optical inspection
Installation note:
Maintain parallel alignment of both rod ends during mounting.
Use locknuts (included) with 12-15 N·m torque. Lubricate rods weekly
with ISO VG32 hydraulic oil in high-cycle applications (>500 strokes/min).
| Property | Property Value |
|---|---|
| sku | SAID40X100S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Cushion Stroke | 27mm |
| Bore Diameter | <40mm> |
| Stroke | 100mm |
