Airtac SAID50 Double Rod Cylinder SAID50X1000S
2. Piston features an asymmetric bidirectional sealing structure with compact dimensions and oil reservoir functionality;
3. Cross-shaped aluminum tube with rodless design for enhanced corrosion resistance. Integrated sensor mounting grooves enable quick installation of sensors;
4. Smooth cushioning adjustment mechanism ensures stable operation;
5. Multiple specifications and mounting accessories available for flexible customization;
6. High-temperature resistant sealing materials extend operational range to 0~150℃.
Category: Double Rod Cylinder | Brand: AirTAC | Series: SAID50
AirTAC SAID50X1000S Double Rod Cylinder Technical Details
- Model: SAID50X1000S
- Type: Double rod ISO 15552 compliant cylinder
- Bore size: Ø50 mm
- Stroke: 1000 mm (customizable up to 2000mm)
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Piston rod material: Hard chrome-plated steel (Ø20mm x 2 rods)
- Tube material: Anodized aluminum alloy
- Seals: NBR/Urethane composite (ISO 5597 standard)
- Port size: G3/8 (M14x1.5 adapter optional)
- Temperature range: -20℃ to 80℃
- Weight: 6.8 kg (±5%)
- Dimensions: 1130mm(L) × 100mm(W) × 62mm(H)
- Rod center distance: 60mm
- Max lateral load: 280N at full extension
- ISO certification: 6431, 21287
High-rigidity twin rod cylinder designed for heavy-duty applications requiring exceptional moment resistance. Features dual piston rods that eliminate rotation during operation and provide balanced thrust forces. The hardened stainless steel rods and triple-lip seals ensure over 3,000km service life under standard conditions.
- Palletizing robot arm actuators
- Plastic injection molding machine ejectors
- Automated warehouse vertical lift systems
- Paper processing equipment tension control
- CNC machine tool clamping mechanisms
Installation guidelines:
For optimal performance, use with MISFC50 series guide brackets.
Lubricate via air line lubricator (ISO VG32 recommended).
Avoid side load exceeding 15% of maximum thrust.
Allow 20mm clearance behind end covers for cushion adjustment.
| Property | Property Value |
|---|---|
| sku | SAID50X1000S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Cushion Stroke | 30mm |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
