Airtac SAID50 Double Rod Cylinder SAID50X100S
2. Piston features an asymmetric bidirectional sealing structure with compact dimensions and oil reservoir functionality;
3. Cross-shaped aluminum tube with rodless design for enhanced corrosion resistance. Integrated sensor mounting grooves enable quick installation of sensors;
4. Smooth cushioning adjustment mechanism ensures stable operation;
5. Multiple specifications and mounting accessories available for flexible customization;
6. High-temperature resistant sealing materials extend operational range to 0~150℃.
Category: Double Rod Cylinder | Brand: AirTAC | Series: SAID50
AirTAC SAID50X100S Dual Rod Cylinder Technical Specifications
- Model: SAID50X100S
- Type: Dual rod, double-acting cylinder
- Bore size: Ø50 mm
- Stroke: 100 mm (adjustable cushion)
- Operating pressure: 0.05–1.0 MPa
- Piston rod diameter: Ø16 mm x 2 rods
- Rod thread: M10x1.25 (both ends)
- Port size: G1/8 (NPT1/8 optional)
- Cushion type: Adjustable elastic buffer
- Operating temperature: -20℃ to 80℃
- Seal material: Nitrile rubber (NBR) + polyurethane (PU)
- Ambient humidity: ≤95% RH
- Weight: 3.8 kg (with standard accessories)
- Dimensions: 200mm(L) × 60mm(W) × 60mm(H)
- Mounting options: Basic type (no foot) with axial mounting holes
- ISO standard: 15552 (VDMA 24562)
High-rigidity dual rod cylinder designed for precision linear motion requiring enhanced stability and moment resistance. Features chrome-plated piston rods with multi-layer sealing system, suitable for heavy-duty cycles. Optional magnetic piston version (SAID50X100S-M9) available for position feedback.
- Precision press mechanisms in die casting machines
- Vertical lifting platforms with guided alignment
- Glass processing equipment with symmetrical force distribution
- Automated welding jigs requiring anti-rotation stability
- Pharmaceutical tablet pressing machines
Installation guidelines:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.3mm minimum clearance between rods during parallel installations.
Use counter-nuts (M10) for rod-end load connections.
| Property | Property Value |
|---|---|
| sku | SAID50X100S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Cushion Stroke | 30mm |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
