Airtac SAID50 Double Rod Cylinder SAID50X130S
2. Piston features an asymmetric bidirectional sealing structure with compact dimensions and oil reservoir functionality;
3. Cross-shaped aluminum tube with rodless design for enhanced corrosion resistance. Integrated sensor mounting grooves enable quick installation of sensors;
4. Smooth cushioning adjustment mechanism ensures stable operation;
5. Multiple specifications and mounting accessories available for flexible customization;
6. High-temperature resistant sealing materials extend operational range to 0~150℃.
Category: Double Rod Cylinder | Brand: AirTAC | Series: SAID50
AirTAC SAID50X130S Dual Rod Cylinder Technical Specifications
- Model: SAID50X130S
- Type: ISO 15552 standard dual-rod cylinder
- Bore size: Ø50 mm
- Stroke: 130 mm (±0.5 mm tolerance)
- Rod diameter: Ø16 mm (both rods)
- Operating pressure: 0.15-1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Temperature range: -20°C to +80°C
- Port size: M5×0.8 (G1/8 adapter optional)
- Piston material: Aluminum alloy with wear-resistant coating
- Rod material: Hard chrome-plated steel (3-5μm coating thickness)
- Seals: NBR (standard), optional Fluorocarbon for high temp
- Mounting: Basic type (axial mounting holes) with optional accessories:
- MF1/MF2 flange mounts
- MP4/MP8 side mounts
- Weight: 2.8 kg (excluding accessories)
- Dimensions:
- Body length: 284 mm (including end cushions)
- Width: 63 mm (square body dimension)
- Height: 63 mm
- Rod extension: 130 mm stroke + 45 mm rod protrusion
High-rigidity dual rod cylinder designed for applications requiring precise linear motion with enhanced moment resistance. Features twin piston rods that eliminate rotational movement and provide balanced force distribution. The hardened stainless steel guide bushing ensures smooth operation under side loads up to 30% of maximum thrust capacity.
- Precision alignment systems in semiconductor manufacturing
- Vertical lifting mechanisms with anti-rotation requirements
- Clamping fixtures requiring synchronized dual-point force application
- Packaging machinery with side-mounted tooling
- Automated inspection equipment needing vibration-free movement
Installation recommendation:
Use alignment jigs during mounting to ensure parallel rod movement.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Maximum side load capacity: 150N at mid-stroke.
Allow 20mm clearance behind rods for full retraction.
| Property | Property Value |
|---|---|
| sku | SAID50X130S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Cushion Stroke | 30mm |
| Bore Diameter | <50mm> |
| Stroke | 130mm |
