Airtac SAID50 Double Rod Cylinder SAID50X140S
2. Piston features an asymmetric bidirectional sealing structure with compact dimensions and oil reservoir functionality;
3. Cross-shaped aluminum tube with rodless design for enhanced corrosion resistance. Integrated sensor mounting grooves enable quick installation of sensors;
4. Smooth cushioning adjustment mechanism ensures stable operation;
5. Multiple specifications and mounting accessories available for flexible customization;
6. High-temperature resistant sealing materials extend operational range to 0~150℃.
Category: Double Rod Cylinder | Brand: AirTAC | Series: SAID50
AirTAC SAID50X140S Double Rod Cylinder Specifications
- Model: SAID50X140S
- Type: ISO 15552 compliant double rod pneumatic cylinder
- Bore size: 50 mm
- Stroke: 140 mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Mounting style: Standard MF1 flange mounting
- Port size: G1/8 (ISO 228-1)
- Piston rod material: Hard chrome-plated steel (Cr-Mo alloy)
- Seal material: NBR (nitrile) with wear-resistant ring
- Weight: 2.5 kg (without accessories)
- Dimensions:
- Body diameter: 50 mm
- Total length (extended): 240 mm
- Height (with mounting flange): 70 mm
- Width (rod-to-rod clearance): 70 mm
- Rod diameter: 16 mm (double rods)
- Max thrust: 1,080 N @ 0.7 MPa
- Max speed: 0.5–1.0 m/s
- Protection rating: IP65 (standard wipers)
- Optional sensors: Built-in magnet compatible with reed switches
High-rigidity dual piston rod cylinder designed for precision linear motion requiring balanced force distribution. The symmetrical rod configuration minimizes lateral deflection under eccentric loads. Features triple sealing (end covers, piston, rod) with corrosion-resistant surface treatment (black oxide coating). Includes shock-absorbing cushions with 20° adjustable screw for smooth end-of-stroke deceleration.
- Precision alignment systems in semiconductor manufacturing
- Simultaneous clamping mechanisms in CNC fixtures
- Vertical lifting platforms with counterbalance control
- Packaging machinery with dual-action pressing
- Automated conveyor diverters requiring bidirectional force
Installation guidelines:
Maintain 0.5mm minimum alignment tolerance between rods and load.
Lubricate with ISO VG32 hydraulic oil during initial setup.
For vertical mounting, install air vents upward.
Recommended maintenance cycle: 2,000 km travel or 12 months.
| Property | Property Value |
|---|---|
| sku | SAID50X140S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Cushion Stroke | 30mm |
| Bore Diameter | <50mm> |
| Stroke | <140mm> |
