Airtac SAID80 Double Rod Cylinder SAID80X100S
2. Piston features specially-shaped bidirectional sealing structure with compact dimensions and integrated oil reservoir capability
3. Cross-reinforced aluminum profile body without tie rods ensures superior corrosion resistance. External sensor mounting grooves enable fast and convenient installation
4. Precision-engineered smooth cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for flexible configuration
6. High-temperature resistant sealing materials support operational range of 0-150°C
Category: Double Rod Cylinders | Brand: AirTAC | Series: SAID80
AirTAC SAID80X100S Dual Rod Cylinder Technical Specifications
- Model: SAID80X100S
- Bore size: Ø80 mm
- Stroke: 100 mm
- Operating pressure: 0.05–1.0 MPa
- Piston rod diameter: Ø20 mm (dual rod design)
- Cushioning type: Adjustable rubber buffer (both ends)
- Mounting style: Basic type (optional flange/clevis mounts available)
- Operating temperature: -20℃ to 80℃
- Port size: G3/8 (NPT1/2 optional)
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal material: NBR (standard)/PU (high-speed version)
- Weight: 2.85 kg (excluding accessories)
- Dimensions: 200mm(L) × 100mm(W) × 100mm(H) (at mid-stroke position)
- Max theoretical thrust: 502 N @0.5 MPa
- Speed range: 50–750 mm/s
- Protection rating: IP54 (standard)/IP67 (optional wiper upgrade)
High-rigidity dual rod cylinder engineered for precision linear motion requiring exceptional lateral load capacity. Features synchronized dual piston rods that eliminate rotational torque, making it ideal for applications demanding straight-line accuracy. The symmetrical design ensures balanced force distribution and reduced bearing wear.
- Precision material handling systems
- Vertical lift mechanisms in automotive assembly
- Glass panel pressing equipment
- High-speed sorting machinery with side-mounted tooling
- Electronics component insertion devices
Installation guidance:
For optimal performance, maintain 0.05-0.1mm alignment tolerance between rod ends and load.
Lubricate with ISO VG32 hydraulic oil during initial installation. Avoid direct side impact forces exceeding 200N.
| Property | Property Value |
|---|---|
| sku | SAID80X100S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 80 mm |
| Stroke | 100mm |
