Airtac SAID80 Double Rod Cylinder SAID80X110S
$149.78
Regular price
$157.28
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAID80X110S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. ISO 15552 (former ISO 6431) standard cylinder design
2. Piston features specially-shaped bidirectional sealing structure with compact dimensions and integrated oil reservoir capability
3. Cross-reinforced aluminum profile body without tie rods ensures superior corrosion resistance. External sensor mounting grooves enable fast and convenient installation
4. Precision-engineered smooth cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for flexible configuration
6. High-temperature resistant sealing materials support operational range of 0-150°C
Category: Double Rod Cylinders | Brand: AirTAC | Series: SAID80
Installation recommendation:
Maintain 0.5-1mm alignment tolerance during mounting. Use rod-end bearings
when lateral forces exceed 10% of maximum thrust. Lubricate with ISO VG32
grade oil for initial operation.
2. Piston features specially-shaped bidirectional sealing structure with compact dimensions and integrated oil reservoir capability
3. Cross-reinforced aluminum profile body without tie rods ensures superior corrosion resistance. External sensor mounting grooves enable fast and convenient installation
4. Precision-engineered smooth cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for flexible configuration
6. High-temperature resistant sealing materials support operational range of 0-150°C
Category: Double Rod Cylinders | Brand: AirTAC | Series: SAID80
AirTAC SAID80X110S Double Rod Cylinder Technical Specifications
- Model: SAID80X110S
- Type: ISO 15552 compliant double rod cylinder
- Bore size: Ø80 mm (±0.08mm tolerance)
- Stroke: 110 mm (customizable 25-500mm)
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Piston rod material: Hard chrome-plated carbon steel (S45C)
- Cylinder tube: Aluminum alloy (Al6063-T5) with hard anodized finish
- Seal material: NBR (Nitrile) standard, optional FKM/Viton
- Temperature range: -20℃ to +80℃
- Rod diameter: Ø20mm (dual rods)
- Mounting types: Basic front flange (NF category), optional rear clevis
- Weight: 3.65 kg (dry, without accessories)
- Dimensions: 252mm(L) × 92mm(W) × 92mm(H)
- Port size: G1/2 (BSPP thread)
- Max thrust: 4,524N at 0.7MPa (push/pull)
- Max speed: 500-800 mm/s (with cushion)
- ISO standard: 15552 (formerly ISO 6431)
Precision-engineered double rod cylinder featuring symmetrical force transmission and enhanced moment resistance. The dual-rod design eliminates rotational torque during operation, making it ideal for applications requiring precise linear motion control. The T-slot mounting surface (per ISO 15552) allows flexible accessory attachment.
Industrial Applications:
- Automated palletizing systems requiring balanced force distribution
- Precision glass cutting machinery with lateral stability needs
- Electronics assembly lines for dual-axis positioning
- Automotive welding jigs requiring anti-rotation features
- Packaging machines with guided tooling plates
Installation recommendation:
Maintain 0.5-1mm alignment tolerance during mounting. Use rod-end bearings
when lateral forces exceed 10% of maximum thrust. Lubricate with ISO VG32
grade oil for initial operation.
Optional accessories:
Magnetic piston (D-M9NW sensor compatible), heat-resistant seals (+120℃ version),
corrosion-resistant coating (salt spray test 500hrs), and rod lock modules.
| Property | Property Value |
|---|---|
| sku | SAID80X110S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 80 mm |
| Stroke | 110mm |
