Airtac SAIF Series Standard Cylinder with Valve SAIF32X100-06A
The AirTAC Airtac SAIF Series Standard Cylinder with Valve SAIF32X100-06A is a genuine double-acting ISO 15552 cylinder with a Ø32mm bore, 100mm stroke and a built-in 4M210-06 5/2 solenoid valve — it switches itself from one coil signal, so no separate remote valve or extra plumbing is needed.
- BoreØ32 mm
- Stroke100 mm
- Built-in valve4M210-06
- Valve port1/8"
- CoilAC220V
- EntryTerminal
About the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100-06A
The AirTAC SAIF32X100-06A is a double-acting ISO 15552 profile cylinder featuring an integrated 4M210-06 5/2 solenoid valve. With a valve orifice of 14.0 mm2 (Cv 0.78), it drives a 32 mm bore that generates 402 N of push force at 0.5 MPa. The unit is configured with an AC220V coil utilizing a terminal electrical entry, drawing 3.5 VA with IP65 protection. Because the cylinder rates to 1.0 MPa but the built-in valve operates at 0.15-0.8 MPa, the practical working range for this assembled unit is 0.15-0.8 MPa.
By default, the piston rod retracts when the coil is energised, though this can be reconfigured to extend-when-energised simply by repositioning the valve. The manifold connects to the cylinder via PU tubing (O8 x O5), and the valve port (1/8 inch, code 06) is distinct from the cylinder port (PT1/8). Switching itself from a single coil signal, this decentralized design eliminates the need for a separate remote valve, reducing panel space and plumbing complexity across large machines.
Airtac SAIF Series Standard Cylinder with Valve SAIF32X100-06A Technical Specifications
| Model | Airtac SAIF Series Standard Cylinder with Valve SAIF32X100-06A |
|---|---|
| Series | SAIF ISO 15552 cylinder with valve |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting, self-valved |
| Cylinder port | G1/8 |
| Rod thread | M10×1.25 |
| PU tube | Ø8 × Ø5 |
| Built-in valve | 4M210-06 (5/2) |
|---|---|
| Valve flow | 14.0 mm² (Cv 0.78) |
| Max frequency | 5 cycle/sec |
| Coil voltage | AC220V · AC 3.5 VA |
| Electrical entry | Terminal · IP65 · B class |
| Response time | 0.05 s and below |
| Operating pressure | 0.15 – 0.8 MPa (valve limit) |
| Speed range | 30 – 800 mm/s |
The cylinder rates to 1.0 MPa but the built-in valve operates 0.15–0.8 MPa, so run the assembled SAIF at 0.15–0.8 MPa. Default: rod retracts when the coil is energised (reconfigurable to extend). Specs follow the official AirTAC SAIF datasheet. Port options: PT / G.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
Sized within the valve's 0.15–0.8 MPa range. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac SAIF Series Standard Cylinder with Valve SAIF32X100-06A
| SAIF | ISO 15552 cylinder with built-in 4M valve. |
|---|---|
| 32×100 | Bore × stroke in mm. |
| -06 | Valve port 1/8" → 4M210-06. |
| A | Coil voltage AC220V. |
| I / (blank) | Terminal electrical entry. |
SAIF does not hold its load without air — the valve routes air, it is not a lock. For load-holding use a SAIL (lock) or BSAI (clamp-lock).
Where the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100-06A Is Used
Decentralized Machine Stations
Ideal for large automated lines where running individual valve tubing back to a central panel is inefficient. The integrated 4M210 valve lets each 32mm cylinder switch independently via a single AC220V signal.
Compact Assembly Automation
Perfect for space-constrained machinery. The built-in valve and manifold block minimize the pneumatic footprint while delivering 402N of push force at 0.5MPa for small part handling.
Retrofit & Upgrades
Simplifies machine upgrades by replacing a standard cylinder and external plumbing with a self-switching unit, cutting down on tubing complexity and installation time.
Is the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100-06A the Right Choice?
Selecting this 32 mm bore is ideal when your application requires around 402 N of push force at 0.5 MPa; if you need greater thrust, stepping up to the 40 mm bore yields 628 N under the same pressure. A self-valved SAIF unit is highly advantageous over a separate cylinder and remote valve when installation space is tight and running tubing back to a central manifold is costly. To replace this assembly correctly, match the 32 mm bore, 100 mm stroke, 4M210-06 valve port, AC220V terminal coil, PT thread, and confirm no -S magnet is required. Since the stroke is 100 mm, side-load concerns are minimal. Note that the built-in 5/2 valve routes air and does not hold the load without live pressure; for positive locking, consider the SAIL series instead.
Quick checklist
- ✓ Force at 0.15–0.8 MPa
- ✓ Coil voltage matches panel
- ✓ Terminal vs grommet entry
- ✓ Retract- or extend-when-energised
- ✓ Load-holding → SAIL / BSAI
Airtac SAIF Series Standard Cylinder with Valve SAIF32X100-06A FAQ
The 32mm bore generates 402N of push force and 345N of pull force at 0.5MPa. The integrated 4M210-06 5/2 valve has an effective area of 14.0 mm2 (Cv 0.78) and a maximum operating frequency of 5 cycles per second.
The built-in 5/2 valve eliminates the need for a separate remote valve, saving space and wiring. By factory default, the rod retracts when the AC220V coil is energised, but this can be reconfigured to extend-when-energised by repositioning the valve.
