Airtac SAIF Series Standard Cylinder with Valve SAIF32X100-06B
The AirTAC Airtac SAIF Series Standard Cylinder with Valve SAIF32X100-06B is a genuine double-acting ISO 15552 cylinder with a Ø32mm bore, 100mm stroke and a built-in 4M210-06 5/2 solenoid valve — it switches itself from one coil signal, so no separate remote valve or extra plumbing is needed.
- BoreØ32 mm
- Stroke100 mm
- Built-in valve4M210-06
- Valve port1/8"
- CoilDC24V
- EntryTerminal
About the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100-06B
The AirTAC SAIF32X100-06B is a double-acting profile cylinder with a built-in 4M210-06 5/2 solenoid valve, delivering a 14.0 mm2 effective area (Cv 0.78). Configured with a DC24V terminal coil drawing 3.0 W, it switches itself from one electrical signal. The cylinder body rates to 1.0 MPa, but the integrated pilot valve limits the practical operating pressure to 0.15-0.8 MPa.
At the 32mm bore, it provides 402N of push force at 0.5 MPa. The factory setting retracts the piston rod when the coil energizes, but you can reposition the valve to extend-when-energized. The manifold connects to the cylinder via O8xO5 PU tubing, and the 1/8" cylinder port differs from the 1/8" valve port.
Airtac SAIF Series Standard Cylinder with Valve SAIF32X100-06B Technical Specifications
| Model | Airtac SAIF Series Standard Cylinder with Valve SAIF32X100-06B |
|---|---|
| Series | SAIF ISO 15552 cylinder with valve |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting, self-valved |
| Cylinder port | G1/8 |
| Rod thread | M10×1.25 |
| PU tube | Ø8 × Ø5 |
| Built-in valve | 4M210-06 (5/2) |
|---|---|
| Valve flow | 14.0 mm² (Cv 0.78) |
| Max frequency | 5 cycle/sec |
| Coil voltage | DC24V · DC 3.0 W |
| Electrical entry | Terminal · IP65 · B class |
| Response time | 0.05 s and below |
| Operating pressure | 0.15 – 0.8 MPa (valve limit) |
| Speed range | 30 – 800 mm/s |
The cylinder rates to 1.0 MPa but the built-in valve operates 0.15–0.8 MPa, so run the assembled SAIF at 0.15–0.8 MPa. Default: rod retracts when the coil is energised (reconfigurable to extend). Specs follow the official AirTAC SAIF datasheet. Port options: PT / G.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
Sized within the valve's 0.15–0.8 MPa range. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac SAIF Series Standard Cylinder with Valve SAIF32X100-06B
| SAIF | ISO 15552 cylinder with built-in 4M valve. |
|---|---|
| 32×100 | Bore × stroke in mm. |
| -06 | Valve port 1/8" → 4M210-06. |
| B | Coil voltage DC24V. |
| I / (blank) | Terminal electrical entry. |
SAIF does not hold its load without air — the valve routes air, it is not a lock. For load-holding use a SAIL (lock) or BSAI (clamp-lock).
Where the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100-06B Is Used
Decentralized Stations
Ideal for large machines where running individual valve tubing back to a central manifold is costly and complex.
Compact Clamping
Delivers 402N push force at 0.5 MPa for small part clamping in tight machinery envelopes.
Space-Constrained Retrofits
Replaces a separate cylinder and valve setup with a single self-switching unit to minimize wiring.
Is the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100-06B the Right Choice?
Choose this self-valved unit to eliminate remote plumbing and save panel space in decentralized machine stations. If your application needs more force, stepping up to the 40mm bore yields 628N of push at 0.5 MPa. The 4M210 valve operates at up to 5 cycles per second, matching the 30-800 mm/s speed range.
This assembly uses a carbon steel rod and PT tapered threads. It does not hold loads without live pressure; the 5/2 valve routes air but is not a lock. For load-holding, consider the SAIL lock cylinder. To replace this unit, match the 32mm bore, 100mm stroke, 1/8" valve port, DC24V terminal coil, and no magnet.
Quick checklist
- ✓ Force at 0.15–0.8 MPa
- ✓ Coil voltage matches panel
- ✓ Terminal vs grommet entry
- ✓ Retract- or extend-when-energised
- ✓ Load-holding → SAIL / BSAI
Airtac SAIF Series Standard Cylinder with Valve SAIF32X100-06B FAQ
The 32mm bore generates 402N push and 345N pull force at 0.5 MPa. The built-in 4M210-06 valve has a 14.0 mm2 orifice with a Cv of 0.78.
This model uses a DC24V terminal coil (3.0 W, IP65). By default, the rod retracts when energized, but you can reposition the valve to extend-when-energized. No separate remote valve is needed.
