Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06A
The AirTAC Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06A is a genuine double-acting ISO 15552 cylinder with a Ø32mm bore, 100mm stroke and a built-in 4M210-06 5/2 solenoid valve — it switches itself from one coil signal, so no separate remote valve or extra plumbing is needed.
- BoreØ32 mm
- Stroke100 mm
- Built-in valve4M210-06
- Valve port1/8"
- CoilAC220V
- EntryTerminal
About the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06A
The AirTAC SAIF32X100S-06A is a double-acting ISO 15552 profile cylinder featuring an integrated 4M210-06 5/2 solenoid valve. This specific SKU is configured with a PT1/8 valve port, an AC220V terminal coil connection, and a built-in magnet (-S) for position sensing with CMSE reed or DMSE electronic switches. The 4M210-06 valve provides a 14.0 mm2 effective area (Cv 0.78) and supports up to 5 cycles per second, driving the 32mm bore to deliver 402N of push force at 0.5 MPa.
Because the cylinder body rates to 1.0 MPa but the built-in valve operates safely between 0.15-0.8 MPa, the practical working range for this assembled unit is 0.15-0.8 MPa. The manifold connects to the cylinder via O8xO5 PU tubing, meaning you only need one coil signal to control the actuator. From the factory, the piston rod retracts when the coil is energised, but you can reposition the valve to achieve extend-when-energised operation if your sequence requires it.
Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06A Technical Specifications
| Model | Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06A |
|---|---|
| Series | SAIF ISO 15552 cylinder with valve |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting, self-valved |
| Cylinder port | G1/8 |
| Rod thread | M10×1.25 |
| PU tube | Ø8 × Ø5 |
| Built-in valve | 4M210-06 (5/2) |
|---|---|
| Valve flow | 14.0 mm² (Cv 0.78) |
| Max frequency | 5 cycle/sec |
| Coil voltage | AC220V · AC 3.5 VA |
| Electrical entry | Terminal · IP65 · B class |
| Response time | 0.05 s and below |
| Operating pressure | 0.15 – 0.8 MPa (valve limit) |
| Speed range | 30 – 800 mm/s |
The cylinder rates to 1.0 MPa but the built-in valve operates 0.15–0.8 MPa, so run the assembled SAIF at 0.15–0.8 MPa. Default: rod retracts when the coil is energised (reconfigurable to extend). Specs follow the official AirTAC SAIF datasheet. Port options: PT / G.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
Sized within the valve's 0.15–0.8 MPa range. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06A
| SAIF | ISO 15552 cylinder with built-in 4M valve. |
|---|---|
| 32×100 | Bore × stroke in mm. |
| -06 | Valve port 1/8" → 4M210-06. |
| A | Coil voltage AC220V. |
| I / (blank) | Terminal electrical entry. |
SAIF does not hold its load without air — the valve routes air, it is not a lock. For load-holding use a SAIL (lock) or BSAI (clamp-lock).
Where the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06A Is Used
Decentralized Assembly Stations
Eliminates the need for remote valve banks on large machines by switching locally from a single AC220V signal, reducing plumbing complexity.
Space-Constrained Automation
The integrated 4M210 valve manifold saves valuable panel space, fitting a complete actuation package into tight machine footprints.
Retrofit and Upgrades
Ideal for upgrading existing setups where running new pneumatic tubing back to a central control panel is costly or impractical.
Is the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06A the Right Choice?
Choose this 32mm bore when you need compact actuation delivering 402N push force at 0.5 MPa; stepping up to a 40mm bore increases that to 628N if your load demands more thrust. The self-valved SAIF architecture is superior to a separate cylinder and remote valve when panel space is tight or you are building decentralized stations across a large machine, as it eliminates long tubing runs and complex wiring. This specific model uses an AC220V terminal entry with PT threaded ports.
When ordering a replacement, verify the 32mm bore, 100mm stroke, 06 (1/8) valve port, AC220V voltage, terminal entry, and the -S magnet requirement. Note that the integrated 5/2 valve routes air and is not a mechanical lock; if your application requires load holding without live pressure, consider the SAIL lock variant instead. The 100mm stroke is well within standard limits, so no side-load guide is strictly necessary, but standard alignment practices should always be followed.
Quick checklist
- ✓ Force at 0.15–0.8 MPa
- ✓ Coil voltage matches panel
- ✓ Terminal vs grommet entry
- ✓ Retract- or extend-when-energised
- ✓ Load-holding → SAIL / BSAI
Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06A FAQ
At 0.5 MPa, this 32mm bore cylinder generates 402N of push force and 345N of pull force. The integrated 4M210-06 valve has an effective area of 14.0 mm2 (Cv 0.78) and can cycle up to 5 times per second.
No separate valve is needed; the built-in 5/2 solenoid valve switches the cylinder directly. By factory default, the rod retracts when the AC220V coil is energised, but this can be reconfigured to extend-when-energised by repositioning the valve.
