Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06B
The AirTAC Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06B is a genuine double-acting ISO 15552 cylinder with a Ø32mm bore, 100mm stroke and a built-in 4M210-06 5/2 solenoid valve — it switches itself from one coil signal, so no separate remote valve or extra plumbing is needed.
- BoreØ32 mm
- Stroke100 mm
- Built-in valve4M210-06
- Valve port1/8"
- CoilDC24V
- EntryTerminal
About the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06B
The AirTAC SAIF32X100S-06B is a double-acting ISO 15552 profile cylinder with a built-in 4M210-06 5/2 solenoid valve, delivering a 14.0 mm2 flow (Cv 0.78). Driven by a DC24V terminal entry coil drawing 3.0 W, it switches itself from one electrical signal. The cylinder port is PT1/8, while the valve features a 1/8 inch port connected via O8xO5 PU tubing.
Although the cylinder body rates to 1.0 MPa, the integrated valve limits the practical operating range to 0.15-0.8 MPa. It delivers 402N of push force at 0.5 MPa. Factory-set to retract when energised, the valve can be repositioned to extend on signal. The -S magnet supports CMSE reed and DMSE electronic sensors.
Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06B Technical Specifications
| Model | Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06B |
|---|---|
| Series | SAIF ISO 15552 cylinder with valve |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting, self-valved |
| Cylinder port | G1/8 |
| Rod thread | M10×1.25 |
| PU tube | Ø8 × Ø5 |
| Built-in valve | 4M210-06 (5/2) |
|---|---|
| Valve flow | 14.0 mm² (Cv 0.78) |
| Max frequency | 5 cycle/sec |
| Coil voltage | DC24V · DC 3.0 W |
| Electrical entry | Terminal · IP65 · B class |
| Response time | 0.05 s and below |
| Operating pressure | 0.15 – 0.8 MPa (valve limit) |
| Speed range | 30 – 800 mm/s |
The cylinder rates to 1.0 MPa but the built-in valve operates 0.15–0.8 MPa, so run the assembled SAIF at 0.15–0.8 MPa. Default: rod retracts when the coil is energised (reconfigurable to extend). Specs follow the official AirTAC SAIF datasheet. Port options: PT / G.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
Sized within the valve's 0.15–0.8 MPa range. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06B
| SAIF | ISO 15552 cylinder with built-in 4M valve. |
|---|---|
| 32×100 | Bore × stroke in mm. |
| -06 | Valve port 1/8" → 4M210-06. |
| B | Coil voltage DC24V. |
| I / (blank) | Terminal electrical entry. |
SAIF does not hold its load without air — the valve routes air, it is not a lock. For load-holding use a SAIL (lock) or BSAI (clamp-lock).
Where the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06B Is Used
Decentralized Assembly Stations
Eliminates the need for a remote valve bank, allowing independent 32mm actuation directly at the workstation using a single DC24V signal.
Compact Sorting Diverters
Provides 402N push force with a built-in 4M210-06 valve, saving space and reducing tubing runs on fast-paced conveyor lines.
Retrofit Automation Cells
Ideal for upgrading older machines where routing new pneumatic tubing to a central manifold is costly or physically constrained.
Is the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06B the Right Choice?
Choose this 32mm bore if your application requires up to 402N push force at 0.5 MPa; step up to the 40mm bore for 628N if higher thrust is needed. A self-valved SAIF eliminates remote plumbing and panel space, making it ideal for decentralized stations. The DC24V terminal coil offers 3.0 W power consumption and IP65 protection.
This assembly does not hold load without live pressure, as the 5/2 valve routes air rather than locking it. For position holding, consider SAIL or BSAI types. Replacement requires matching the 32mm bore, 100mm stroke, 06 valve port, DC24V voltage, terminal entry, PT thread, and -S magnet. At 100mm stroke, side-load guides are unnecessary.
Quick checklist
- ✓ Force at 0.15–0.8 MPa
- ✓ Coil voltage matches panel
- ✓ Terminal vs grommet entry
- ✓ Retract- or extend-when-energised
- ✓ Load-holding → SAIL / BSAI
Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06B FAQ
At 0.5 MPa, this 32mm bore cylinder provides 402N push and 345N pull force. The integrated 4M210-06 5/2 valve has an effective area of 14.0 mm2 (Cv 0.78) and a maximum frequency of 5 cycles per second.
No, it features an integrated 4M210 valve. It operates from a single DC24V terminal coil (3.0 W, IP65). By default, the rod retracts when the coil is energised, but this can be reconfigured to extend-when-energised by repositioning the valve.
