Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06C
The AirTAC Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06C is a genuine double-acting ISO 15552 cylinder with a Ø32mm bore, 100mm stroke and a built-in 4M210-06 5/2 solenoid valve — it switches itself from one coil signal, so no separate remote valve or extra plumbing is needed.
- BoreØ32 mm
- Stroke100 mm
- Built-in valve4M210-06
- Valve port1/8"
- CoilAC110V
- EntryTerminal
About the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06C
The AirTAC SAIF32X100S-06C is a double-acting ISO 15552 profile cylinder featuring a built-in 4M210-06 5/2 solenoid valve. This integrated assembly delivers a 14.0 mm2 effective area (Cv 0.78) and operates on an AC110V terminal connection drawing 3.5 VA. Because the cylinder body rates to 1.0 MPa but the internal piloted valve limits to 0.15-0.8 MPa, the practical working pressure for this valved unit is 0.15-0.8 MPa. It generates 402 N of push force at 0.5 MPa, utilizing a carbon steel piston rod and PT1/8 cylinder ports.
Equipped with a magnet for CMSE reed and DMSE electronic sensors, this unit switches itself from a single coil signal, eliminating remote valve plumbing. The manifold connects via an O8xO5 PU tube, and the factory default setting retracts the rod when the coil is energised. You can reconfigure the valve position to extend-when-energised if your sequence requires it, making it ideal for decentralized stations across large machines.
Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06C Technical Specifications
| Model | Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06C |
|---|---|
| Series | SAIF ISO 15552 cylinder with valve |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting, self-valved |
| Cylinder port | G1/8 |
| Rod thread | M10×1.25 |
| PU tube | Ø8 × Ø5 |
| Built-in valve | 4M210-06 (5/2) |
|---|---|
| Valve flow | 14.0 mm² (Cv 0.78) |
| Max frequency | 5 cycle/sec |
| Coil voltage | AC110V · AC 3.5 VA |
| Electrical entry | Terminal · IP65 · B class |
| Response time | 0.05 s and below |
| Operating pressure | 0.15 – 0.8 MPa (valve limit) |
| Speed range | 30 – 800 mm/s |
The cylinder rates to 1.0 MPa but the built-in valve operates 0.15–0.8 MPa, so run the assembled SAIF at 0.15–0.8 MPa. Default: rod retracts when the coil is energised (reconfigurable to extend). Specs follow the official AirTAC SAIF datasheet. Port options: PT / G.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
Sized within the valve's 0.15–0.8 MPa range. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06C
| SAIF | ISO 15552 cylinder with built-in 4M valve. |
|---|---|
| 32×100 | Bore × stroke in mm. |
| -06 | Valve port 1/8" → 4M210-06. |
| C | Coil voltage AC110V. |
| I / (blank) | Terminal electrical entry. |
SAIF does not hold its load without air — the valve routes air, it is not a lock. For load-holding use a SAIL (lock) or BSAI (clamp-lock).
Where the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06C Is Used
Decentralized Machine Stations
Eliminates the need for a central valve manifold, allowing independent AC110V control of individual 32mm bore actuators across large factory layouts.
Space-Tight Handling
The integrated 4M210 valve and manifold block save panel space, fitting neatly into compact assembly cells where remote tubing is restricted.
Retrofit Automation
Perfect for upgrading older lines where adding new air lines is costly; simply supply air and a 110V signal to the self-contained cylinder.
Is the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06C the Right Choice?
Choose this 32mm bore if your application requires around 402 N of push force at 0.5 MPa; stepping down is not an option, but moving up to a 40mm bore yields 628 N if your load demands more power. The SAIF32X100S-06C with its built-in 4M210-06 valve and AC110V terminal coil is optimal for space-tight machines where running separate valve tubing and wiring is costly or impractical. Remember that the 5/2 valve routes air and the end cushions only decelerate near stroke end—neither holds a load without live pressure. For true position holding, look to the SAIL lock or BSAI clamp-lock series.
When ordering a replacement, verify the 100mm stroke, 1/8 cylinder port, 06 (1/8) valve port, AC110V voltage, terminal entry, PT thread, and the -S magnet. The 100mm stroke is well within the 1000mm maximum standard for this bore, so no side-load guide concerns apply at this length.
Quick checklist
- ✓ Force at 0.15–0.8 MPa
- ✓ Coil voltage matches panel
- ✓ Terminal vs grommet entry
- ✓ Retract- or extend-when-energised
- ✓ Load-holding → SAIL / BSAI
Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06C FAQ
The 32mm bore generates 402 N of push force and 345 N of pull force at 0.5 MPa. The built-in 4M210-06 5/2 valve provides an effective area of 14.0 mm2 (Cv 0.78) with a maximum operating frequency of 5 cycles per second.
The integrated 5/2 solenoid valve holds its position via internal pilot pressure, not a spring. The factory default retracts the rod when the AC110V coil is energised, but you can reposition the valve to extend-when-energised. It operates safely within 0.15-0.8 MPa.
