Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06F
The AirTAC Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06F is a genuine double-acting ISO 15552 cylinder with a Ø32mm bore, 100mm stroke and a built-in 4M210-06 5/2 solenoid valve — it switches itself from one coil signal, so no separate remote valve or extra plumbing is needed.
- BoreØ32 mm
- Stroke100 mm
- Built-in valve4M210-06
- Valve port1/8"
- CoilDC12V
- EntryTerminal
About the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06F
The AirTAC SAIF32X100S-06F is a double-acting profile cylinder with an integrated 4M210-06 5/2 solenoid valve, delivering a 14.0 mm2 effective area (Cv 0.78). Driven by a DC12V terminal coil drawing 3.0 W, it eliminates remote plumbing. While the bare cylinder rates to 1.0 MPa, the built-in valve limits the practical SAIF operating range to 0.15-0.8 MPa. It generates 402N of push force at 0.5 MPa.
By default, the piston rod retracts when the coil is energised, but you can reconfigure it to extend-when-energised by repositioning the valve. The manifold uses an O8 x O5 PU tube to bridge the valve and cylinder, and the valve port (1/8) is distinct from the cylinder port (1/8). Fitted with a magnet, it supports CMSE reed and DMSE electronic sensors for precise positioning.
Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06F Technical Specifications
| Model | Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06F |
|---|---|
| Series | SAIF ISO 15552 cylinder with valve |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting, self-valved |
| Cylinder port | G1/8 |
| Rod thread | M10×1.25 |
| PU tube | Ø8 × Ø5 |
| Built-in valve | 4M210-06 (5/2) |
|---|---|
| Valve flow | 14.0 mm² (Cv 0.78) |
| Max frequency | 5 cycle/sec |
| Coil voltage | DC12V · DC 3.0 W |
| Electrical entry | Terminal · IP65 · B class |
| Response time | 0.05 s and below |
| Operating pressure | 0.15 – 0.8 MPa (valve limit) |
| Speed range | 30 – 800 mm/s |
The cylinder rates to 1.0 MPa but the built-in valve operates 0.15–0.8 MPa, so run the assembled SAIF at 0.15–0.8 MPa. Default: rod retracts when the coil is energised (reconfigurable to extend). Specs follow the official AirTAC SAIF datasheet. Port options: PT / G.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
Sized within the valve's 0.15–0.8 MPa range. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06F
| SAIF | ISO 15552 cylinder with built-in 4M valve. |
|---|---|
| 32×100 | Bore × stroke in mm. |
| -06 | Valve port 1/8" → 4M210-06. |
| F | Coil voltage DC12V. |
| I / (blank) | Terminal electrical entry. |
SAIF does not hold its load without air — the valve routes air, it is not a lock. For load-holding use a SAIL (lock) or BSAI (clamp-lock).
Where the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06F Is Used
Decentralized Machine Stations
Ideal for large machines with multiple stations, eliminating long tubing runs by controlling the cylinder locally via a single DC12V signal.
Compact Assembly Automation
Suits space-tight machinery where mounting a separate remote valve is difficult, providing 402N push force in a compact ISO 15552 profile.
Retrofit Positioning
Perfect for upgrading existing lines where running new valve tubing is costly, using the integrated 4M210-06 valve and CMSE/DMSE sensors.
Is the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06F the Right Choice?
Choose this self-valved SAIF unit when installing decentralized stations across a large machine, as it switches itself from one coil signal to save panel space and wiring. If your application requires higher thrust, step up to the 40mm bore, which provides 628N push force at 0.5 MPa. Conversely, if you need less force and tighter spacing, a smaller bore is ideal. The 32mm bore achieves a maximum 82 kgf at 1.0 MPa. For stroke lengths of 300mm or more, ensure you have adequate guide arrangements to handle side loads.
When replacing this unit, verify the 32mm bore, 100mm stroke, 1/8 valve port, DC12V voltage, PT tapered thread, terminal entry, and the -S magnet. Note that the 5/2 valve routes air and is not a lock; if you need true load-holding, consider the SAIL lock cylinder instead.
Quick checklist
- ✓ Force at 0.15–0.8 MPa
- ✓ Coil voltage matches panel
- ✓ Terminal vs grommet entry
- ✓ Retract- or extend-when-energised
- ✓ Load-holding → SAIL / BSAI
Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06F FAQ
The 32mm bore generates 402N push and 345N pull force at 0.5 MPa, reaching a maximum of 82 kgf at 1.0 MPa. The built-in 4M210-06 valve has a 14.0 mm2 orifice with a Cv of 0.78.
The built-in 5/2 valve allows the cylinder to switch itself without a separate remote valve, saving space and plumbing. Factory-set to retract when the DC12V coil is energised, it can be reconfigured to extend-when-energised by repositioning the valve.
