Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-08C
The AirTAC Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-08C is a genuine double-acting ISO 15552 cylinder with a Ø32mm bore, 100mm stroke and a built-in 4M210-08 5/2 solenoid valve — it switches itself from one coil signal, so no separate remote valve or extra plumbing is needed.
- BoreØ32 mm
- Stroke100 mm
- Built-in valve4M210-08
- Valve port1/4"
- CoilAC110V
- EntryTerminal
About the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-08C
The AirTAC SAIF32X100S-08C is a double-acting ISO 15552 profile cylinder with a built-in 4M210-08 5/2 solenoid valve, providing a Cv of 0.89 and a 16.0 mm2 effective orifice. Driven by an AC110V terminal entry coil drawing 3.5 VA, it switches itself from a single electrical signal. The assembly includes a -S magnet for position sensing with CMSE reed or DMSE electronic switches. Although the cylinder body rates to 1.0 MPa, the integrated valve limits the practical working pressure to 0.15-0.8 MPa.
In this 32 mm bore configuration, the cylinder delivers 402 N of push force and 345 N of pull force at 0.5 MPa. The manifold connects to the cylinder via an O8 x O5 PU tube, meaning the 1/4" valve port and the 1/8" cylinder port are distinctly separate. Factory-set to retract the rod when the coil is energised, the valve can be physically repositioned to extend-when-energised if your logic requires it.
Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-08C Technical Specifications
| Model | Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-08C |
|---|---|
| Series | SAIF ISO 15552 cylinder with valve |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting, self-valved |
| Cylinder port | G1/8 |
| Rod thread | M10×1.25 |
| PU tube | Ø8 × Ø5 |
| Built-in valve | 4M210-08 (5/2) |
|---|---|
| Valve flow | 16.0 mm² (Cv 0.89) |
| Max frequency | 5 cycle/sec |
| Coil voltage | AC110V · AC 3.5 VA |
| Electrical entry | Terminal · IP65 · B class |
| Response time | 0.05 s and below |
| Operating pressure | 0.15 – 0.8 MPa (valve limit) |
| Speed range | 30 – 800 mm/s |
The cylinder rates to 1.0 MPa but the built-in valve operates 0.15–0.8 MPa, so run the assembled SAIF at 0.15–0.8 MPa. Default: rod retracts when the coil is energised (reconfigurable to extend). Specs follow the official AirTAC SAIF datasheet. Port options: PT / G.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
Sized within the valve's 0.15–0.8 MPa range. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-08C
| SAIF | ISO 15552 cylinder with built-in 4M valve. |
|---|---|
| 32×100 | Bore × stroke in mm. |
| -08 | Valve port 1/4" → 4M210-08. |
| C | Coil voltage AC110V. |
| I / (blank) | Terminal electrical entry. |
SAIF does not hold its load without air — the valve routes air, it is not a lock. For load-holding use a SAIL (lock) or BSAI (clamp-lock).
Where the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-08C Is Used
Decentralized Assembly Stations
Eliminates the need for a remote valve bank on large machines, driving the 32 mm actuator directly from a local AC110V signal.
Space-Constrained Automation
The integrated manifold block saves valuable panel and footprint space by mounting the 5/2 valve directly onto the profile cylinder.
Retrofit Conveyor Systems
Ideal for upgrading existing lines where running new pneumatic tubing back to a central control cabinet is costly or impractical.
Is the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-08C the Right Choice?
Select this 32 mm bore unit for lighter-duty positioning where a 402 N push force at 0.5 MPa is sufficient; step up to the 40 mm bore if you need 628 N of push force. A self-valved SAIF excels over a separate cylinder and remote valve in decentralized stations by eliminating long tubing runs, saving panel space, and requiring only a single wire to the machine. The carbon steel rod and PT tapered threads suit standard industrial air systems.
For replacements, match the 32 mm bore, 100 mm stroke, 1/4" valve port, AC110V terminal coil, PT thread type, and the -S magnet. Remember that the 5/2 valve routes air but does not lock the load mechanically—select an AirTAC SAIL lock cylinder if unpowered position holding is required.
Quick checklist
- ✓ Force at 0.15–0.8 MPa
- ✓ Coil voltage matches panel
- ✓ Terminal vs grommet entry
- ✓ Retract- or extend-when-energised
- ✓ Load-holding → SAIL / BSAI
Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-08C FAQ
The 32 mm bore generates 402 N of push and 345 N of pull force at 0.5 MPa. The built-in 4M210-08 valve provides an effective area of 16.0 mm2 (Cv 0.89) with a maximum frequency of 5 cycles per second.
The integrated 5/2 valve allows the cylinder to switch itself from one coil signal, saving space and plumbing. By default, the rod retracts when the AC110V coil is energised, but repositioning the valve changes it to extend-when-energised.
