Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06C
The AirTAC Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06C is a genuine double-acting ISO 15552 cylinder with a Ø32mm bore, 125mm stroke and a built-in 4M210-06 5/2 solenoid valve — it switches itself from one coil signal, so no separate remote valve or extra plumbing is needed.
- BoreØ32 mm
- Stroke125 mm
- Built-in valve4M210-06
- Valve port1/8"
- CoilAC110V
- EntryTerminal
About the Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06C
The AirTAC SAIF32X125S-06C is a double-acting profile cylinder with a built-in 4M210-06 5/2 solenoid valve, delivering a 14.0 mm2 effective area (Cv 0.78) flow rate. Driven by an AC110V terminal coil consuming 3.5 VA, it activates in 0.05 s or less with IP65 protection. The integrated manifold uses an O8 x O5 PU tube to bridge the valve and cylinder, meaning the 1/8" cylinder port and 1/8" valve port are distinct connections that must not be confused. Equipped with a magnet, it works seamlessly with CMSE reed and DMSE electronic sensors.
Although the cylinder body rates to 1.0 MPa, the practical operating range for this valved assembly is 0.15-0.8 MPa. At 0.5 MPa it generates 402N of push force and 345N of pull force. The factory setting retracts the piston rod when the coil is energised, but you can reposition the valve to extend-when-energised. Because it switches itself from one coil signal, no remote valve is needed, saving panel space and reducing plumbing for decentralized machine stations.
Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06C Technical Specifications
| Model | Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06C |
|---|---|
| Series | SAIF ISO 15552 cylinder with valve |
| Bore size | Ø32 mm |
| Stroke | 125 mm |
| Acting type | Double acting, self-valved |
| Cylinder port | G1/8 |
| Rod thread | M10×1.25 |
| PU tube | Ø8 × Ø5 |
| Built-in valve | 4M210-06 (5/2) |
|---|---|
| Valve flow | 14.0 mm² (Cv 0.78) |
| Max frequency | 5 cycle/sec |
| Coil voltage | AC110V · AC 3.5 VA |
| Electrical entry | Terminal · IP65 · B class |
| Response time | 0.05 s and below |
| Operating pressure | 0.15 – 0.8 MPa (valve limit) |
| Speed range | 30 – 800 mm/s |
The cylinder rates to 1.0 MPa but the built-in valve operates 0.15–0.8 MPa, so run the assembled SAIF at 0.15–0.8 MPa. Default: rod retracts when the coil is energised (reconfigurable to extend). Specs follow the official AirTAC SAIF datasheet. Port options: PT / G.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
Sized within the valve's 0.15–0.8 MPa range. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06C
| SAIF | ISO 15552 cylinder with built-in 4M valve. |
|---|---|
| 32×125 | Bore × stroke in mm. |
| -06 | Valve port 1/8" → 4M210-06. |
| C | Coil voltage AC110V. |
| I / (blank) | Terminal electrical entry. |
SAIF does not hold its load without air — the valve routes air, it is not a lock. For load-holding use a SAIL (lock) or BSAI (clamp-lock).
Where the Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06C Is Used
Decentralized Assembly Stations
Eliminates remote valve banks by switching locally via the AC110V terminal coil, cutting tubing runs across large factory layouts.
Compact Component Handling
Delivers 402N push force at 0.5 MPa in tight machinery where mounting a separate valve and manifold block is physically impossible.
Sensor-Ready Automation
The integrated -S magnet works with CMSE and DMSE switches for precise end-of-stroke detection without adding external brackets.
Is the Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06C the Right Choice?
Choose this 32mm bore if your application requires around 402N push force at 0.5 MPa; step up to the 40mm bore if you need 628N push force. The self-valved SAIF design beats a separate cylinder plus remote valve when space is tight and running tubing across a large machine is costly. For load-holding, note that the 5/2 valve routes air but does not lock the load—use SAIL for a mechanical lock instead.
This configuration features a 125mm stroke, a 1/8" valve port, an AC110V terminal connection, and PT tapered threading. It includes an -S magnet for position sensing. Since the stroke is under 300mm, standard side-load guide considerations are minimal, but always verify load alignment per ISO 15552 mounting interface dimensions.
Quick checklist
- ✓ Force at 0.15–0.8 MPa
- ✓ Coil voltage matches panel
- ✓ Terminal vs grommet entry
- ✓ Retract- or extend-when-energised
- ✓ Load-holding → SAIL / BSAI
Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06C FAQ
The 32mm bore generates 402N push and 345N pull force at 0.5 MPa. The built-in 4M210-06 5/2 valve provides a 14.0 mm2 effective area (Cv 0.78) with a maximum frequency of 5 cycles per second.
The built-in 4M210 valve allows the cylinder to control itself from one AC110V coil signal, removing the need for separate remote valves. By default, the rod retracts when energised, but you can reconfigure it to extend-when-energised by repositioning the valve.
