Airtac SAIJ160 Adjustable Cylinder SAIJ160BX10-10S
The AirTAC SAIJ160 Adjustable Cylinder SAIJ160BX10-10S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø160mm bore and 10mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ160 mm
- Stroke10 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX10-10S
The AirTAC SAIJ160X10-10-S is a double-acting ISO 15552 profile cylinder engineered for precise short-travel tasks. The rear adjuster screw provides a 0-10 mm usable travel window, allowing you to dial in the exact end-position without adding external stops.
This variant includes a SUS304 stainless steel rod for superior corrosion resistance and is equipped with a magnet for CMSE reed and DMSE electronic sensors. It uses PT tapered ports and retains the standard extruded aluminum barrel with dual-side sensor grooves, operating at speeds of 30-500 mm/s.
Airtac SAIJ160 Adjustable Cylinder SAIJ160BX10-10S Technical Specifications
| Model | Airtac SAIJ160 Adjustable Cylinder SAIJ160BX10-10S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø160 mm |
| Stroke | 10 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø160mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 9425 N | 9425 N |
| 0.7 MPa | 13195 N | — |
| Max (@1.0 MPa) | 1922 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAIJ160 Adjustable Cylinder SAIJ160BX10-10S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 160 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX10-10S Is Used
Product Changeover Adjustment
Quickly dial in the stroke end-position during machine setup and product size changes using the rear adjustment screw.
Heavy-Duty Clamping
Ideal for securely clamping large components, utilizing the SUS304 rod for corrosion resistance and the magnet for position sensing.
Is the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX10-10S the Right Cylinder?
Select this specific model when an application demands high force over a very short distance and requires exact end-position tuning. If you need less force, stepping down to a 125 mm bore yields 6136 N at 0.5 MPa, but the 160 mm bore is necessary for heavy pressing or clamping. Choose the SAIJ adjustable-stroke series over a fixed SAI cylinder when product changeovers require variable end-stops at the machine setup phase.
For any stroke of 300 mm or more, an external guide is recommended to handle side loads, though this 10 mm stroke is inherently rigid. Remember that the rear adjuster acts only as a travel stop and does not hold the load without live air; for true load-holding, use an external rod lock or pilot-operated check valve. This configuration uses PT ports, a SUS304 rod, and the -S magnet option.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAIJ160 Adjustable Cylinder SAIJ160BX10-10S FAQ
The rear adjuster screw allows you to shorten the effective travel by up to 10 mm from the 10 mm nominal stroke, creating a 0-10 mm usable window. It acts as a mechanical stop to fine-tune the end position and is not a lock, meaning live air is required to hold the load.
