Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-30S
The AirTAC SAIJ160 Adjustable Cylinder SAIJ160BX1000-30S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø160mm bore and 1000mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ160 mm
- Stroke1000 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-30S
The AirTAC SAIJ160X1000-30-S is a double-acting ISO 15552 profile cylinder featuring a rear stroke adjuster that allows you to fine-tune the end position. With a nominal 1000 mm stroke and a 30 mm adjustment range, it provides a usable travel window of 970-1000 mm.
Equipped with a SUS304 stainless steel rod (code B) and PT tapered ports, it is built for demanding environments. The extruded aluminum barrel includes sensor grooves on both sides, and the integrated magnet (-S) supports CMSE reed and DMSE electronic sensors for precise position feedback. Speeds reach 30-500 mm/s, and the mounting set includes Basic, FA, LB, TC, FTC, TCM1, and TCM2.
Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-30S Technical Specifications
| Model | Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-30S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø160 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø160mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 9425 N | 9425 N |
| 0.7 MPa | 13195 N | — |
| Max (@1.0 MPa) | 1922 kgf | |
Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-30S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 160 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-30S Is Used
Machine Setup & Changeover
Dial in the exact 970-1000 mm travel window during line changeovers without physically replacing the cylinder or bolting on external stoppers.
Variable End Stops
Adjust the retract position on the fly to accommodate different product sizes moving down a heavy-duty conveyor system.
Is the Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-30S the Right Cylinder?
Choose this adjustable-stroke model when your application requires exact end-position tuning at commissioning or during product changeover without swapping the cylinder or adding external stops. For this 1000 mm stroke, an external guide is recommended to manage side loads on the long unsupported rod. To replace an ISO 15552 cylinder, match the 160 mm bore, 1000 mm stroke, 30 mm adjustment, PT ports, and -S magnet.
Remember that the rear adjuster acts as a travel stop, not a lock. The SAIJ160X1000-30-S will not hold a load without live air pressure; for true load-holding, consider the SAIL or BSAI series.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAIJ160 Adjustable Cylinder SAIJ160BX1000-30S FAQ
The rear adjusting screw acts as a mechanical stop that lets you shorten the effective stroke by up to 30 mm. This creates a 970-1000 mm usable travel window, allowing you to fine-tune the end position at commissioning without changing the cylinder.
The maximum push force at 1.0 MPa is 18095 N.
