Airtac SAIJ200 Adjustable Cylinder SAIJ200AX100-50S
The AirTAC Airtac SAIJ200 Adjustable Cylinder SAIJ200AX100-50S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø200mm bore and 100mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ200 mm
- Stroke100 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
About the Airtac SAIJ200 Adjustable Cylinder SAIJ200AX100-50S
The AirTAC SAIJ200X100-50-S is a double-acting, single-rod ISO 15552 profile cylinder equipped with a rear stroke adjuster. It delivers massive thrust, pushing 15708N and pulling 15080N at 0.5 MPa, making it suited for heavy-duty operations. The integrated -S magnet enables position sensing with AirTAC CMSE reed and DMSE electronic switches.
This specific SKU features a 100mm nominal stroke paired with a 50mm adjustment range, creating a 50-100mm usable travel window for exact end-position tuning. It incorporates a SUS420J2 stainless steel rod for enhanced corrosion resistance and utilizes PT tapered port threads. The extruded aluminum barrel includes sensor grooves on both sides, and the adjustable stopper allows you to trim the retract distance without adding external stops.
Airtac SAIJ200 Adjustable Cylinder SAIJ200AX100-50S Technical Specifications
| Model | Airtac SAIJ200 Adjustable Cylinder SAIJ200AX100-50S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø200 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø200mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 15708 N | 15080 N |
| 0.7 MPa | 21991 N | — |
| Max (@1.0 MPa) | 3204 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAIJ200 Adjustable Cylinder SAIJ200AX100-50S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 200 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAIJ200 Adjustable Cylinder SAIJ200AX100-50S Is Used
Heavy Press Tuning
Fine-tune the 50-100mm travel window during heavy press setup to accommodate varying material thicknesses without changing the cylinder.
Product Diversion
Adjust the retract end-stop on the fly for different package sizes moving along a high-thrust conveyor line.
Machine Changeover
Rapidly reconfigure end positions during production line changeovers, leveraging the 50mm adjustment screw to skip external stop hardware.
Is the Airtac SAIJ200 Adjustable Cylinder SAIJ200AX100-50S the Right Cylinder?
Selecting this 200mm bore cylinder is appropriate when an application demands up to 15708N of push force at 0.5 MPa; stepping down to a 160mm bore would reduce that output to 10053N. The 50mm adjustment range is highly valuable for product changeovers, allowing operators to dial in the 50-100mm travel window directly at commissioning rather than swapping out a fixed-stroke SAI cylinder. Because the stroke is 100mm, side-load risks are moderate, but always ensure proper external guiding for the massive 40mm rod.
When replacing an ISO 15552 cylinder, match the 200mm bore, 100mm stroke, 50mm adjustment, PT G3/4 port, and the -S magnet requirement. Note that the rear adjuster functions strictly as a travel stop and does not hold the load without live air; for pneumatic load-holding, consider the SAIL or BSAI series. The SAIJ mounting set includes Basic, FA, LB, TC, FTC, TCM1, and TCM2, omitting FB, CA, CB, and CR.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAIJ200 Adjustable Cylinder SAIJ200AX100-50S FAQ
At 0.5 MPa operating pressure, this 200mm bore cylinder provides 15708N of push force and 15080N of pull force. It can reach a maximum push force of 28274N at 0.9 MPa.
The rear adjuster acts as a mechanical stop that shortens the effective stroke. For this 100mm nominal stroke model, the -50 code allows you to trim the travel back by up to 50mm, creating a 50-100mm usable window. It is a stop, not a lock, and requires live air to hold position.
