Airtac SAIJ200 Adjustable Cylinder SAIJ200AX1000-10S
The AirTAC Airtac SAIJ200 Adjustable Cylinder SAIJ200AX1000-10S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø200mm bore and 1000mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ200 mm
- Stroke1000 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
About the Airtac SAIJ200 Adjustable Cylinder SAIJ200AX1000-10S
The AirTAC SAIJ200X1000-10-S is a double-acting ISO 15552 profile cylinder engineered for heavy-duty applications, delivering a substantial push force of 15708 Newtons at 0.5 MPa. It features a robust 40 mm carbon steel rod paired with an SUS420J2 stainless steel surface (code A) to resist corrosion and handle high side loads. Equipped with a magnet (-S), it integrates seamlessly with AirTAC CMSE reed and DMSE electronic solid-state sensors mounted in the dual-side extruded aluminum barrel grooves.
This model provides a 10 mm rear stroke adjustment, creating a precise 990-1000 mm usable travel window for fine-tuning the retract end position during commissioning. The rear adjuster functions strictly as a travel stop to set deceleration alongside the variable air cushions; it is not a locking mechanism. For applications requiring load holding without live air pressure, an external rod lock or related AirTAC SAIL pneumatic lock cylinder is required.
Airtac SAIJ200 Adjustable Cylinder SAIJ200AX1000-10S Technical Specifications
| Model | Airtac SAIJ200 Adjustable Cylinder SAIJ200AX1000-10S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø200 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø200mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 15708 N | 15080 N |
| 0.7 MPa | 21991 N | — |
| Max (@1.0 MPa) | 3204 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAIJ200 Adjustable Cylinder SAIJ200AX1000-10S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 200 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAIJ200 Adjustable Cylinder SAIJ200AX1000-10S Is Used
Heavy Press Tuning
Dial in the exact 990-1000 mm end-stop during press commissioning to accommodate varying material thicknesses without swapping out the entire cylinder.
Large Product Changeover
Adjust the retract position on the fly for different pallet sizes on a heavy-duty conveyor line, utilizing the 10 mm adjustment window for quick setup.
Automated Assembly Indexing
Index large structural components precisely using the 15708 N push force, relying on the rear stopper to fine-tune the final resting position.
Is the Airtac SAIJ200 Adjustable Cylinder SAIJ200AX1000-10S the Right Cylinder?
Selecting this 200 mm bore cylinder is ideal when your application demands up to 15708 N of push force at 0.5 MPa and requires exact end-position tuning without adding external stops. If your force requirements are lower, stepping down to a 160 mm bore yields 10053 N of push force, optimizing air consumption. The adjustable stroke is particularly valuable for machine setups requiring product changeovers, allowing you to dial in the 990-1000 mm travel window on the fly. Because this cylinder features a 1000 mm stroke, the extended 40 mm rod is subject to increased bending moments; an external guide rail must be used to prevent excessive side-loading and premature seal wear.
To replace an ISO 15552 cylinder with this model, verify the 200 mm bore, 1000 mm nominal stroke, 10 mm adjustment range, G3/4 port size (PT tapered thread type), and the -S magnet requirement. The SAIJ mounting interface supports Basic, FA, LB, TC, FTC, TCM1, and TCM2 configurations, deliberately omitting FB, CA, CB, and CR brackets. Operating speed ranges from 30-500 mm/s, making it suitable for controlled, heavy movements.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAIJ200 Adjustable Cylinder SAIJ200AX1000-10S FAQ
At 0.5 MPa operating pressure, this 200 mm bore cylinder provides a push force of 15708 N and a pull force of 15080 N. At the maximum operating pressure of 1.0 MPa, it can deliver a maximum push force equivalent to 3204 kgf.
The rear adjuster acts as an external stopper that allows you to shorten the effective stroke by up to 10 mm, providing a usable travel window of 990-1000 mm. It only sets the travel end and does not lock or hold the load without continuous air pressure.
