Airtac SAIJ200 Adjustable Cylinder SAIJ200AX1000-30
The AirTAC Airtac SAIJ200 Adjustable Cylinder SAIJ200AX1000-30 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø200mm bore and 1000mm stroke, G3/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ200 mm
- Stroke1000 mm
- Port sizeG3/4
- Acting typeDouble acting
- Rod threadM36×2
- CushionAdjustable, 50 mm
About the Airtac SAIJ200 Adjustable Cylinder SAIJ200AX1000-30
The AirTAC SAIJ200X1000-30 is a double-acting ISO 15552 profile cylinder engineered for heavy-duty applications, featuring a rear mechanical adjuster that permits up to 30 mm of stroke reduction. This creates a precise 970-1000 mm usable travel window, enabling exact end-position tuning at commissioning without swapping out the cylinder or adding external stops. Delivering 15708 N of push force at 0.5 MPa, it handles massive loads with ease.
This unit incorporates a SUS420J2 stainless steel rod (material code A) for superior corrosion resistance and operates at 30-500 mm/s. The extruded aluminum barrel includes sensor grooves on both sides for mounting CMSE reed or DMSE solid-state switches. The rear adjuster acts strictly as a travel stop to set deceleration limits, meaning it will not hold the load without live air pressure; for true load-holding, consider the SAIL or BSAI series.
Airtac SAIJ200 Adjustable Cylinder SAIJ200AX1000-30 Technical Specifications
| Model | Airtac SAIJ200 Adjustable Cylinder SAIJ200AX1000-30 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø200 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G3/4 |
| Rod thread | M36×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 50 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø200mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 15708 N | 15080 N |
| 0.7 MPa | 21991 N | — |
| Max (@1.0 MPa) | 3204 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAIJ200 Adjustable Cylinder SAIJ200AX1000-30
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 200 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAIJ200 Adjustable Cylinder SAIJ200AX1000-30 Is Used
Heavy Press Positioning
Dial in the 970-1000 mm travel window on large stamping or press lines to accommodate varying material thicknesses without re-engineering the entire cylinder station.
Product Line Changeover
Quickly fine-tune the retract end-position by up to 30 mm during automated packaging size transitions, ensuring precise stops without adding external mechanical spacers.
Large Assembly Tuning
Leverage the 15708 N push force at 0.5 MPa to move heavy pallets or assemblies, using the rear adjuster to set exact deceleration points during initial commissioning.
Is the Airtac SAIJ200 Adjustable Cylinder SAIJ200AX1000-30 the Right Cylinder?
Selecting this 200 mm bore cylinder is ideal when your application requires the maximum standard thrust capacity, pushing 15708 N at 0.5 MPa or 21991 N at 0.7 MPa. If your force requirements are lower, stepping down to a 160 mm bore saves space and yields 10053 N at 0.5 MPa. The adjustable stroke is specifically chosen for machine setups needing variable end-stops during product changeovers rather than relying on a fixed-stroke SAI cylinder.
Because the stroke is 1000 mm, the 40 mm diameter rod and M36x2 thread will experience significant side-load leverage if the load is unsupported; an external guide mechanism is mandatory to prevent rod binding. For an exact ISO 15552 replacement match, verify the 1000 mm stroke, 30 mm adjustment range, PT tapered G3/4 port, and the reduced SAIJ mounting set (Basic, FA, LB, TC, FTC, TCM1, TCM2). Note that this SAIJ variant omits the FB, CA, CB, and CR mounts.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAIJ200 Adjustable Cylinder SAIJ200AX1000-30 FAQ
The rear adjuster acts as a mechanical stop that allows you to shorten the nominal 1000 mm stroke by up to 30 mm, providing a usable travel window of 970-1000 mm. It sets the end-position and deceleration limit but does not lock or hold the load without live air pressure.
At an operating pressure of 0.5 MPa, this 200 mm bore cylinder provides 15708 N of push force and 15080 N of pull force. At 0.7 MPa, the push force increases to 21991 N.
