AirTAC SAI Series · ISO 15552 Cylinder

Airtac SAIJ50 Adjustable Cylinder SAIJ50X10-10

The AirTAC SAIJ50 Adjustable Cylinder SAIJ50X10-10 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø50mm bore and 10mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ50 mm
  • Stroke10 mm
  • Port sizeG1/4
  • Acting typeDouble acting
  • Rod threadM16×1.5
  • CushionAdjustable, 30 mm
$80.46 $87.96Save 8% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SAIJ50 stroke, mounting and version on one page All SAIJ50 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SAIJ50 Adjustable Cylinder SAIJ50X10-10

The AirTAC SAIJ50X10-10 is a double-acting ISO 15552 profile cylinder equipped with a rear stroke adjuster. It provides a 10mm nominal stroke that can be dialed back by up to 10mm, yielding a highly precise 0-10mm usable travel window for exact end-position tuning at commissioning.

The adjustment is managed via a rear stopper screw rather than a mechanical lock, meaning it only sets the travel end and will not hold a load without live air pressure. Built with a carbon steel rod and a 20mm diameter, it handles standard operational stresses well. It features PT tapered port threads and variable air cushions at both ends to decelerate the motion smoothly.

Airtac SAIJ50 Adjustable Cylinder SAIJ50X10-10 Technical Specifications

ModelAirtac SAIJ50 Adjustable Cylinder SAIJ50X10-10
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ50 mm
Stroke10 mm
Acting typeDouble acting
Port sizeG1/4
Rod threadM16×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø50mm)

PressurePush forcePull force
0.5 MPa825 N825 N
0.7 MPa1155 N—
Max (@1.0 MPa)168 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SAIJ50 Adjustable Cylinder SAIJ50X10-10

SAIISO 15552 profile-barrel cylinder series.
50Bore size in mm.
×10Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac SAIJ50 Adjustable Cylinder SAIJ50X10-10 Is Used

precision_manufacturing

Precision Clamping

Dial in the exact 0-10mm travel needed to clamp delicate workpieces without over-stressing the fixture.

tune

Machine Commissioning

Fine-tune the retract end-stop during initial machine setup to perfectly time short-motion sequences.

settings_input_component

Product Changeover

Quickly adjust the stroke window on automated lines when switching to a slightly different product size.

Is the Airtac SAIJ50 Adjustable Cylinder SAIJ50X10-10 the Right Cylinder?

Choose this 50mm bore adjustable-stroke cylinder when an application requires on-the-fly end-stop tuning without swapping out the physical cylinder or adding external stops. If your setup needs less force, stepping down to a 40mm bore yields 628N at 0.5 MPa; for heavier loads, a 63mm bore provides 1559N. Since this is a short-stroke model, side-load concerns are minimal, but always ensure the load is guided externally.

This model serves as a direct ISO 15552 mounting-interface replacement, matching the 50mm bore, 10mm stroke, 10mm adjustment, PT port threads, and standard carbon steel rod. Note that the rear adjuster acts only as a travel stop; for true load-holding without live air pressure, consider the SAIL or BSAI series instead.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SAIJ50 Adjustable Cylinder SAIJ50X10-10 FAQ

The rear adjuster screw lets you shorten the 10mm nominal stroke by up to 10mm, creating a 0-10mm travel window. It functions as an end-stop, not a load-holding lock.
