Airtac SAIJ50 Adjustable Cylinder SAIJ50X10-10S
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality;
3. Cross-braced aluminum tube design eliminates tie rods, enhancing corrosion resistance. External sensor mounting grooves enable rapid installation;
4. Smooth cushioning adjustment mechanism for stable operation;
5. Multiple cylinder specifications and mounting accessories available for customized configurations; 6. High-temperature resistant sealing materials support operational range of 0°C to 150°C.
Category: Standard Cylinders , Brand: AirTAC , Series: SAIJ50 *Note: Technical features optimized for professional terminology including "asymmetric bidirectional sealing", "cross-braced aluminum tube", and "smooth cushioning adjustment" to align with pneumatic component specifications.*
AirTAC SAIJ50X10-10S Adjustable Cylinder Specifications
- Model: SAIJ50X10-10S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø50 mm
- Stroke: 10 mm (adjustable via external stopper)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -10℃ to 80℃
- Cushioning: Rubber buffer + adjustable screw
- Mounting style: Basic type (axial foot mounting)
- Port size: Rc1/4 (G1/4 optional)
- Material: Aluminum alloy barrel, hardened stainless steel piston rod
- Weight: 1.85 kg ±2%
- Dimensions:
- Total length (retracted): 146 mm
- Body width: 62 mm
- Height (with mounting foot): 82 mm
- Rod end type: Female thread M10×1.25
- Piston seal: High-wear resistance polyurethane
Precision-adjustable compact cylinder featuring micro-stroke control through external mechanical stoppers. The anodized barrel provides corrosion resistance in humid environments, while the double-lip rod seal prevents leakage during high-frequency operations (up to 3 cycles/sec). Includes magnetic piston for position sensing compatibility.
- Precision clamping in CNC tool changers
- Thickness calibration systems in paper processing
- Micro-positioning in semiconductor handling robots
- Pressure adjustment mechanisms in plastic injection molds
- Conveyor gate control for small parcel sorting
Adjustment tip:
Lock adjustment screws with 1.2-1.5 N·m torque after positioning.
Lubricate stopper threads monthly with ISO VG32 hydraulic oil.
Avoid side-load forces exceeding 15N.
Use guided units for lateral load applications.
| Property | Property Value |
|---|---|
| sku | SAIJ50X10-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | <10mm> |
