Airtac SAIJ50 Adjustable Cylinder SAIJ50X1000-20
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality;
3. Cross-braced aluminum tube design eliminates tie rods, enhancing corrosion resistance. External sensor mounting grooves enable rapid installation;
4. Smooth cushioning adjustment mechanism for stable operation;
5. Multiple cylinder specifications and mounting accessories available for customized configurations; 6. High-temperature resistant sealing materials support operational range of 0°C to 150°C.
Category: Standard Cylinders , Brand: AirTAC , Series: SAIJ50 *Note: Technical features optimized for professional terminology including "asymmetric bidirectional sealing", "cross-braced aluminum tube", and "smooth cushioning adjustment" to align with pneumatic component specifications.*
AirTAC SAIJ50X1000-20 Adjustable Stroke Cylinder Specifications
- Model: SAIJ50X1000-20
- Type: Double-acting adjustable stroke cylinder
- Bore diameter: 50mm (ISO 6432 standard)
- Stroke: 1000mm (adjustable through mechanical stopper)
- Adjustment range: 0-1000mm continuous positioning
- Operating pressure: 0.05–0.8 MPa
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Mounting style: Front flange/Foot mount/Rear flange (optional)
- Port size: G1/8 (NPT1/8 optional)
- Rod material: Chrome-plated steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 8.7kg ±3% (including mounting accessories)
- Dimensions: 1205mm(L) × 80mm(W) × 80mm(H) (max extended length)
- Rod thread: M16×1.5 (external)
- Lubrication: Pre-lubricated (Use ISO VG32 turbine oil if needed)
High-precision adjustable stroke cylinder with dual-position locking mechanism, featuring a corrosion-resistant hard anodized barrel and precision ground piston rod. The SAIJ series incorporates a unique stroke adjustment system with position-locking hex nuts and graduated scale (1mm increments) for repeatable positioning. Requires 5μm filtered air and periodic lubrication for optimal performance.
- Variable position clamping in CNC machine tools
- Conveyor gate positioning in packaging lines
- Automotive assembly line press-fitting operations
- Lumber processing pressure control systems
- Elevator door adjustment mechanisms
Installation note:
Mounting surface flatness must be within 0.2mm/m. For vertical installations,
use the auxiliary support bracket (optional accessory ASM-50). Avoid side
loads exceeding 30N. Stroke adjustment should be performed at mid-pressure (0.3MPa).
| Property | Property Value |
|---|---|
| sku | SAIJ50X1000-20 |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
