Airtac SAIJ50 Adjustable Cylinder SAIJ50X1000-20S
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality;
3. Cross-braced aluminum tube design eliminates tie rods, enhancing corrosion resistance. External sensor mounting grooves enable rapid installation;
4. Smooth cushioning adjustment mechanism for stable operation;
5. Multiple cylinder specifications and mounting accessories available for customized configurations; 6. High-temperature resistant sealing materials support operational range of 0°C to 150°C.
Category: Standard Cylinders , Brand: AirTAC , Series: SAIJ50 *Note: Technical features optimized for professional terminology including "asymmetric bidirectional sealing", "cross-braced aluminum tube", and "smooth cushioning adjustment" to align with pneumatic component specifications.*
AirTAC SAIJ50X1000-20S Adjustable Cylinder Specifications
- Model: SAIJ50X1000-20S
- Type: Adjustable stroke double-acting cylinder
- Bore size: Ø50 mm
- Stroke: 1000 mm (adjustable)
- Mounting style: 20S - Front flange with rectangular base
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion at both ends
- Port size: Rc1/4 (NPT1/4 optional)
- Piston rod material: Hard chrome-plated steel
- Cylinder tube: Aluminum alloy with hard anodized surface
- Seal material: Polyurethane (NBR optional)
- Weight: Approx. 5.8 kg (without accessories)
- Dimensions:
- Length: 1050 mm (full extension)
- Width: 80 mm (mounting base width)
- Height: 60 mm (cylinder diameter with mounting)
High-precision industrial cylinder designed for long-stroke applications requiring precise position control. Features dual adjustable mechanical stops (±3mm fine-tuning range) and corrosion-resistant construction. The 20S mounting base provides stable fixation for vertical/horizontal installations. Requires ISO 8573-1:2010 [4:4:3] class compressed air.
- Automated production line positioning systems
- Palletizing robot end-effector actuators
- Sheet metal press feeding mechanisms
- Automotive assembly line clamping fixtures
- Packaging machine pusher mechanisms
Installation note:
Lubricate rod with ISO VG32 hydraulic oil before initial use.
Maintain 0.5mm minimum clearance between adjustable stops during operation.
Not recommended for side load applications exceeding 50N.
| Property | Property Value |
|---|---|
| sku | SAIJ50X1000-20S |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
