Airtac SAIJ50 Adjustable Cylinder SAIJ50X1000-40
2. Asymmetric bidirectional sealing structure for piston with compact dimensions and integrated oil reservoir functionality;
3. Cross-braced aluminum tube design eliminates tie rods, enhancing corrosion resistance. External sensor mounting grooves enable rapid installation;
4. Smooth cushioning adjustment mechanism for stable operation;
5. Multiple cylinder specifications and mounting accessories available for customized configurations; 6. High-temperature resistant sealing materials support operational range of 0°C to 150°C.
Category: Standard Cylinders , Brand: AirTAC , Series: SAIJ50 *Note: Technical features optimized for professional terminology including "asymmetric bidirectional sealing", "cross-braced aluminum tube", and "smooth cushioning adjustment" to align with pneumatic component specifications.*
AirTAC SAIJ50X1000-40 Adjustable Cylinder Technical Details
- Full model: SAIJ50X1000-40
- Series: SAI-J (Adjustable Stroke Series)
- Bore size: Ø50 mm
- Stroke length: 1000 mm (±0.5mm repeatability)
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-750 mm/s (cushioned)
- Mounting type: MF1 (Front flange) / MP2 (Rear pivot) optional
- Cushioning: Adjustable hydraulic shock absorber
- Rod end: External M16×1.5 thread
- Ambient temperature: -10℃ to 80℃
- Lubrication: Pre-lubricated (Grease port optional)
- Material: Aluminum barrel (hard anodized) / CR steel rod
- Port size: G1/8 (NPT1/8 optional)
- Weight: ~6.5 kg (without mounting brackets)
- Dimensions: 1200mm(L) × 50mm(Ø) × 80mm(Mounting base width)
High-precision long-stroke cylinder with position lock mechanism, featuring a unique dual-scale position indicator (metric/imperial) on the rod. The hardened chromium rod with multi-lip seal ensures leak-free operation in dusty environments. Requires 5μm filtered air and regular lubrication intervals (2000km stroke travel).
- Paper converting machinery - web tension control
- Automotive welding fixtures - multi-position clamping
- Textile processing - adjustable fabric feed systems
- Woodworking CNC - programmable press mechanisms
- Packaging lines - variable height product ejection
Installation protocol:
Requires rigid mounting surface with flatness ≤0.1mm/m. For vertical installations,
use counterbalance valves. Alignment tolerance: ±0.5° angular misalignment maximum.
Break-in procedure: 50% pressure for 500 cycles before full load operation.
| Property | Property Value |
|---|---|
| sku | SAIJ50X1000-40 |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
