Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X10-10S
$101.39
Regular price
$108.89
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAIJ63X10-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
SAIJ63 Adjustable Cylinder
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
Installation note:
Use locknuts (not included) on adjustment screws after calibration.
Maintain 0.5-1mm gap between stopper and cylinder head during final
adjustment to prevent over-compression. Lubricate with ISO VG32
hydraulic oil if using non-lubricated air.
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63X10-10S Adjustable Stroke Cylinder Specifications
- Model: SAIJ63X10-10S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 63mm (ISO 6432 standard)
- Stroke: 10mm (adjustable via external stop screws)
- Operating pressure: 0.05–1.0 MPa
- Medium: Dry air (lubricated or non-lubricated)
- Operation direction: Bidirectional operation
- Cushion type: Rubber buffer + external stroke adjustment
- Mounting type: Basic type (no built-in mounting)
- Port size: M5x0.8 (standard), optional G1/8
- Temperature range: -20℃ to 80℃
- Piston material: Aluminum alloy hard anodized
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (standard), optional FKM
- Weight: 0.98kg ±5% (without accessories)
- Dimensions: 142mm(L) × 63mm(W) × 63mm(H)
- Rod end: Female thread M10x1.25
- Max theoretical force: 312N @ 0.63MPa
- Max speed: 500mm/s
- Protection rating: IP54 (standard sealing)
Precision adjustable stroke cylinder featuring dual external micrometer-style adjustment screws (±2mm stroke modification range). The chrome-plated piston rod and integrated shock absorbers enable precise positioning in repetitive motion applications. Requires 5μm filtered air for optimal seal longevity.
Typical Applications:
- Precision clamping fixtures in CNC machining centers
- Micro-positioning in semiconductor handling systems
- Force-controlled pressing mechanisms
- Automated inspection equipment with variable stroke requirements
- Pharmaceutical capsule filling machines
Installation note:
Use locknuts (not included) on adjustment screws after calibration.
Maintain 0.5-1mm gap between stopper and cylinder head during final
adjustment to prevent over-compression. Lubricate with ISO VG32
hydraulic oil if using non-lubricated air.
| Property | Property Value |
|---|---|
| sku | SAIJ63X10-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | <10mm> |
