Airtac SAIJ63 Adjustable Stroke Air Cylinder SAIJ63X1000-100
1. ISO15552 (formerly ISO6431) standard compliant cylinder
2. Features asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir function in piston sealing
3. H-shaped aluminum tubing with rodless design enhances corrosion resistance; External sensor mounting grooves enable quick installation
4. Smooth and stable cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for versatile applications
6. High-temperature resistant sealing materials support operating temperature range of 0~150℃
Category: Standard Cylinders | Brand: AIRTAC | Series: SAIJ63
AirTAC SAIJ63 Adjustable Cylinder SAIJ63X1000-100 Technical Details
- Model: SAIJ63X1000-100
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø63mm
- Stroke: 1000mm (maximum adjustable range)
- Operating pressure: 0.05-1.0 MPa
- Cushioning type: Adjustable air cushion (both ends)
- Mounting style: Front/rear flange or foot mounting (MF1/MF2)
- Port size: Rc1/4 (G1/4 optional)
- Operating temperature: -10℃ to 80℃
- Piston rod material: Chrome-plated carbon steel (S45C)
- Cylinder tube: Aluminum alloy with hard anodized surface
- Seal material: NBR + PU combination
- Weight: Approximately 2.8kg (excluding mounting accessories)
- Dimensions: 1185mm(L) × 80mm(W) × 80mm(H) (at full extension)
- Rod end thread: M20×1.5 (male)
- Max theoretical thrust: 3100N at 0.63MPa
High-precision long-stroke cylinder featuring micro-adjustment capability (±0.5mm repeatability) through integrated stroke adjustment mechanism. The corrosion-resistant design incorporates dual dust rings and wear-resistant seals, optimized for high-cycle applications. Requires 5μm filtered lubricated air (ISO 8573-1 class 3-4-3).
- Automated assembly line positioning systems
- Large-format CNC machine tool clamping
- Packaging machinery with variable product sizes
- Automotive welding fixture applications
- Material handling systems requiring precise stop positions
Installation tip:
Use alignment jigs during mounting to ensure parallel installation within
0.2mm/m tolerance. Apply silicone-free lubricant (ISO VG32) to rod threads
before stroke adjustment.
Critical note:
Maximum side load capacity 150N - Exceeding this limit requires
additional guide mechanism. Avoid full-stroke operation at speeds
above 1000mm/s without cushion adjustment.
| Property | Property Value |
|---|---|
| sku | SAIJ63X1000-100 |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | <1000mm> |
