Airtac SAILB Rear Lock Cylinder SAILB100X25S
2. Unlocking modes: Automatic and Manual.
Category: Locking Cylinders | Brand: AirTAC | Series: SAILB （Note: Professional term adjustments include "Locking Cylinder" as industry-standard terminology, "Unlocking modes" for operational clarity, and maintaining brand capitalization consistency. HTML tags preserved as requested.）
AirTAC SAILB100X25S Locking Cylinder Technical Details
- Model: SAILB100X25S
- Type: Double-acting pneumatic cylinder with mechanical lock
- Bore size: Ø100mm
- Stroke: 25mm
- Operating pressure: 0.2–1.0 MPa
- Locking mechanism: Spring-assisted pneumatic release
- Mounting style: Front flange/Foot mount (MF1/MF2 optional)
- Cushioning: Adjustable air cushion (both ends)
- Temperature range: -10℃ to 80℃
- Rod material: Chrome-plated steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU combination
- Weight: 3.8kg ±2%
- Dimensions: 225mm(L) × 132mm(W) × 132mm(H)
- Rod thread: M20×1.5 external thread
- Lock holding force: 7,850N max
- Response time (lock release): ≤0.3s at 0.5MPa
Heavy-duty locking cylinder featuring dual safety mechanisms - maintains position during power loss through mechanical interlock. Precision ground rod with triple sealing system ensures leak-free operation. The 5-stage surface treatment process provides corrosion resistance in humid environments (salt spray test passed 500hrs). Requires 0.5-50μm filtered air with ISO VG32 equivalent lubrication.
- Mold clamping safety interlocks in injection molding
- Vertical load holding in automated warehousing lifts
- Position retention in automotive welding fixtures
- Emergency stop systems for press machinery
- Stage equipment positioning in theater automation
Installation protocol:
Always engage lock mechanism during maintenance using manual override port (M5×0.8).
Maintain 0.3-0.5mm clearance between lock collar and mounting surface. Lubricate guide bushings
with ISO VG32 oil monthly under continuous operation.
| Property | Property Value |
|---|---|
| sku | SAILB100X25S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | <25 mm> |
| Lock Position | Rear Cover with Lock Type |
