Airtac SAILF Front Locking Pneumatic Cylinder SAILF100X125S
2. Unlocking modes: Automatic release and Manual override.
Category: Locking Cylinders | Brand: AIRTAC | Series: SAILF
AirTAC SAILF Series Front Lock Cylinder SAILF100X125S Technical Specifications
- Model: SAILF100X125S
- Type: Double-acting cylinder with front mechanical lock
- Bore size: Ø100mm
- Stroke: 125mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Locking force: 4,500N (max, at 0.5MPa)
- Lock mechanism: Wedge-type mechanical lock
- Operation direction: Dual action (air consumption: 1.57L/stroke)
- Port size: 1/4 NPT (G1/4 optional)
- Seal material: Nitrile rubber (NBR) with wear-resistant ring
- Temperature range: -20℃ to 80℃
- Rod material: Chrome-plated steel (Cr-Mo)
- Tube material: Anodized aluminum alloy
- Weight: 3.8kg (excluding accessories)
- Dimensions: 345mm(L) × 100mm(W) × 100mm(H)
Heavy-duty locking cylinder featuring instantaneous position holding capability through its integrated wedge-lock mechanism. The dual piston design ensures stable locking force distribution, with precision ground rod (h8 class tolerance) for smooth operation. Meets ISO 15552 standard mounting dimensions with multiple sensor slot options.
- Press machine safety interlocks
- Automated welding fixture position retention
- Vertical lifting system emergency brake
- Die-casting mold clamping security
- Assembly line pallet stoppers
Critical installation notes: Requires air lubrication (ISO 8573-1 class 4 or cleaner). Lock engagement timing must be synchronized with position sensors. Prohibited from side load applications exceeding 0.5mm misalignment. Recommend monthly lock mechanism inspection in high-cycle operations (＞500,000 cycles/year).
- Mounting brackets: MA-100F (front flange), MA-100T (trunnion)
- Magnetic sensor: D-A93 (2-wire) or D-A96 (3-wire)
- Lock release kit: LK-100S (manual override tool)
| Property | Property Value |
|---|---|
| sku | SAILF100X125S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | 125mm |
| Lock Position | Front Cover with Lock |
