Airtac SAILF Front Locking Pneumatic Cylinder SAILF100X160S
2. Unlocking modes: Automatic release and Manual override.
Category: Locking Cylinders | Brand: AIRTAC | Series: SAILF
AirTAC SAILF100X160S Front Locking Cylinder Technical Details
- Model: SAILF100X160S
- Bore size: 100mm
- Stroke: 160mm
- Operation type: Double-acting with mechanical lock
- Working pressure: 0.1-1.0 MPa
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Locking mechanism: Spring-loaded wedge block (front side)
- Port size: G3/8 (NPT1/2 optional)
- Temperature range: -20℃ to 80℃
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR + PU composite seals
- Weight: 5.8kg (with standard accessories)
- Dimensions: 240mm(L) × 118mm(W) × 118mm(H)
- Protection class: IP54 (standard), IP67 (optional)
- Max locking force: 3,200N (at 0.63MPa)
Heavy-duty locking cylinder with fail-safe position retention capability. Features dual-position sensor slots (inductive sensor compatible) and corrosion-resistant construction. The integrated wedge locking mechanism engages automatically upon pressure loss, making it ideal for vertical load applications. Requires filtered lubricated air (ISO 8573-1 class 3.4.2).
- Press machine safety brakes
- Elevator emergency stop systems
- Automated warehouse vertical lift positioning
- Injection molding machine core pulls
- Solar panel tilt adjustment mechanisms
Installation guidelines:
Mount in vertical orientation with lock side downward. Allow minimum 50mm
clearance around locking mechanism for maintenance. Perform weekly
lubrication checks during initial 3-month run-in period.
| Property | Property Value |
|---|---|
| sku | SAILF100X160S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | 160mm |
| Lock Position | Front Cover with Lock |
