Airtac SAILF Front Locking Pneumatic Cylinder SAILF40X450
2. Unlocking modes: Automatic release and Manual override.
Category: Locking Cylinders | Brand: AIRTAC | Series: SAILF
AirTAC SAILF40X450 Front Lock Cylinder Specifications
- Model: SAILF40X450
- Type: Double-acting cylinder with mechanical locking mechanism
- Bore size: 40mm
- Stroke: 450mm
- Operating pressure: 0.15–0.8 MPa
- Locking force: 350N (at 0.5MPa)
- Mounting style: Standard foot mounting (ISO 15552 compatible)
- Port size: 1/8" NPT (M5 optional)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Seal material: NBR + Polyurethane composite
- Temperature range: -20℃ to 80℃
- Weight: 3.5kg ±2%
- Dimensions: 550mm(L) × 48mm(W) × 48mm(H)
- Rod thread: M16×1.5
- Repeat positioning accuracy: ±0.2mm
- Protection rating: IP67 (with optional wiper seal)
Heavy-duty locking cylinder featuring precision ground rod and dual-stage sealing system. The integrated mechanical lock mechanism prevents unintended movement under load disconnection, with manual override capability. Chrome-plated piston rod and aluminum alloy barrel ensure corrosion resistance in harsh environments.
- Automated assembly line positioning fixtures
- Vertical load holding in material handling systems
- Machine tool clamping devices requiring vibration resistance
- Overhead crane brake systems
- Safety interlocks in press machinery
Installation note:
Locking mechanism requires manual release before initial operation.
Maintain 0.1-0.3mm clearance between lock nut and mounting surface.
Lubricate with ISO VG32 hydraulic oil for optimal performance.
Critical parameters:
- Maximum side load: 120N
- Lock engagement time: ≤0.5s after pressure release
- Minimum holding pressure: 0.3MPa for full locking force
| Property | Property Value |
|---|---|
| sku | SAILF40X450 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <40mm> |
| Stroke | 450mm |
| Lock Position | Front Cover with Lock |
