Airtac SAILF Front Locking Pneumatic Cylinder SAILF40X700
2. Unlocking modes: Automatic release and Manual override.
Category: Locking Cylinders | Brand: AIRTAC | Series: SAILF
AirTAC SAILF40X700 Front Lock Cylinder Technical Details
- Model: SAILF40X700
- Bore size: 40mm (ISO 6432 standard)
- Stroke: 700mm (customizable up to 1000mm)
- Locking mechanism: Pneumatic pilot-operated dual piston lock
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable air cushion at both ends
- Port size: G1/8 (NPT1/8 optional)
- Ambient temperature: -20℃ to 80℃
- Locking force: ≥850N at 0.5MPa
- Repeat positioning accuracy: ±0.5mm
- Seal material: Heat-resistant NBR (HNBR available for high-temp)
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Weight: 6.8kg (dry, without accessories)
- Dimensions: 870mm(L) × 60mm(W) × 60mm(H) (extended length)
- Mounting options: MF1/MF2 flange, basic fixed, or foot-mounted
- ISO standard: 15552 compliant
High-precision locking cylinder with fail-safe position retention capability, featuring integrated mechanical-pneumatic braking. The SAILF series utilizes dual-piston wedge locking technology that activates within 0.3 seconds of air pressure loss, making it ideal for vertical load applications. Special hardened guide rings prevent rod deflection during emergency stops.
- Automated warehouse vertical lift position locking
- Press machine mid-stroke emergency stop systems
- Solar panel tilt adjustment mechanisms
- Robotic welding arm position hold during power failure
- Elevator safety brake redundancy systems
Installation requirements:
Requires minimum 0.4MPa pilot pressure for reliable lock disengagement.
Lubricate with ISO VG32 hydraulic oil if used in vertical downward orientation.
Maintain 0.5mm minimum clearance between lock housing and mounting surface.
| Property | Property Value |
|---|---|
| sku | SAILF40X700 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <40mm> |
| Stroke | 700mm |
| Lock Position | Front Cover with Lock |
