Airtac SAILF Front Locking Pneumatic Cylinder SAILF50X700
2. Unlocking modes: Automatic release and Manual override.
Category: Locking Cylinders | Brand: AIRTAC | Series: SAILF
AirTAC SAILF Front Lock Cylinder SAILF50X700 Technical Details
- Model: SAILF50X700
- Type: Double-acting front lock cylinder
- Bore size: Ø50mm
- Stroke: 700mm
- Operating pressure: 0.1-1.0 MPa
- Locking force: 3,500N (at 0.5MPa)
- Locking method: Mechanical wedge mechanism
- Cushioning: Adjustable air cushion (both ends)
- Piston speed: 50-800mm/s
- Ambient temperature: -10℃ to 80℃
- Mounting type: Basic (optional flange/clevis mounts)
- Port size: M16×1.5 (G1/2 optional)
- Seal material: Polyurethane (NBR optional)
- Weight: 6.8kg (dry state)
- Dimensions: 1,015mm(L) × 68mm(W) × 68mm(H)
- Rod thread: M20×1.5 (external)
- Protection class: IP65 (standard), IP67 (optional)
Heavy-duty locking cylinder with fail-safe mechanical wedge system, designed for vertical load holding applications. Features chrome-plated piston rod (25μm thickness) and hardened cylinder tube (Rc40-50 hardness). Requires 40μm filtered air with ISO VG32 lubricator for optimal performance.
- Press machine safety interlocks
- Automated welding fixture position locks
- Elevator emergency braking systems
- Material handling vertical load stabilization
- Die casting machine mold locking
Installation critical:
Must maintain ≤0.5mm alignment tolerance between piston rod and load path.
Apply lithium soap grease (No.2) to locking wedge monthly.
Minimum 150mm free space required at rod end for maintenance access.
| Property | Property Value |
|---|---|
| sku | SAILF50X700 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <50mm> |
| Stroke | 700mm |
| Lock Position | Front Cover with Lock |
