Airtac SAU Standard Air Cylinder SAU32X104
$45.71
Regular price
$53.21
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAU32X104
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enterprise-standard pneumatic cylinder compliant with proprietary specifications;
2. Features asymmetric bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir functionality;
3. Constructed with octagonal aluminum tubing (non-tie-rod design), offering enhanced corrosion resistance. Equipped with built-in sensor mounting grooves for simplified installations;
4. Compact stroke length compared to ISO 15662 compliant cylinders of equivalent bore sizes in SAU series;
5. Incorporates adjustable cushioning mechanism for smooth end-of-stroke deceleration;
6. Shares universal mounting accessories compatibility with SC series cylinders;
7. Utilizes high-temperature resistant sealing compounds for operational range of 0-150°C.
Category: Standard Cylinders | Brand: AIRTAC® | Series: SAU
Installation Guidelines:
2. Features asymmetric bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir functionality;
3. Constructed with octagonal aluminum tubing (non-tie-rod design), offering enhanced corrosion resistance. Equipped with built-in sensor mounting grooves for simplified installations;
4. Compact stroke length compared to ISO 15662 compliant cylinders of equivalent bore sizes in SAU series;
5. Incorporates adjustable cushioning mechanism for smooth end-of-stroke deceleration;
6. Shares universal mounting accessories compatibility with SC series cylinders;
7. Utilizes high-temperature resistant sealing compounds for operational range of 0-150°C.
Category: Standard Cylinders | Brand: AIRTAC® | Series: SAU
AirTAC SAU Standard Cylinder SAU32X104 Technical Specifications
- Model Code Breakdown: SAU32X104
- SAU: Standard Air Cylinder Series
- 32: Bore size (32mm)
- X: Double-acting with auto switch groove
- 104: Stroke length (104mm)
- Bore Diameter: 32mm (±0.5mm tolerance)
- Stroke Tolerance: +2.0mm/-0mm
- Operating Pressure: 0.1-0.9 MPa
- Cushioning Type: Adjustable rubber buffer (both ends)
- Piston Speed: 50-750 mm/s (optimal range 200-500 mm/s)
- Ambient Temperature: -20℃ to 80℃ (non-freezing)
- Port Size: Rc1/8 (NPT1/8 optional)
- Mounting Types: Basic MF1 (ISO 15552 standard)
- Rod End Thread: M12×1.25 (external)
- Material Construction:
- Tube: Aluminum alloy hard oxidation
- Piston Rod: Chrome-plated steel (Cr equivalent ≥0.8μm)
- Seals: NBR (Nitrile) standard
- Weight: 1.65kg (excluding accessories)
- Dimensions:
- Total Length: 214mm (stroke 104 + base length)
- Body Diameter: 42mm (max cylinder OD)
- Mounting Width: 32mm (MF1 bracket interface)
- Rod Extension Length: 136mm (max extended position)
High-precision ISO-compliant pneumatic cylinder featuring wear-resistant construction and precision honed tube. The SAU32X104 combines 0.1MPa low-pressure operation capability with 1.5x safety factor pressure resistance. Includes magnetic piston for sensor compatibility and dual cushioning adjustment screws for smooth end-stroke deceleration.
Industrial Applications:
- Automated assembly line clamping mechanisms
- Printing press paper feed systems
- CNC machine tool door actuators
- Food processing conveyor gate controls
- Automotive welding fixture positioning
Installation Guidelines:
- Align piston rod within 0.5° angular misalignment tolerance
- Use M6 mounting bolts (8.8 grade min) with 10Nm torque
- Maintain 0.5-1mm/m lubricant film thickness when using oil mist lubrication
- For vertical mounting, install rod end downward to prevent seal drainage
| Property | Property Value |
|---|---|
| sku | SAU32X104 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 104 mm |
