Airtac SAU Standard Air Cylinder SAU32X105
2. Features asymmetric bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir functionality;
3. Constructed with octagonal aluminum tubing (non-tie-rod design), offering enhanced corrosion resistance. Equipped with built-in sensor mounting grooves for simplified installations;
4. Compact stroke length compared to ISO 15662 compliant cylinders of equivalent bore sizes in SAU series;
5. Incorporates adjustable cushioning mechanism for smooth end-of-stroke deceleration;
6. Shares universal mounting accessories compatibility with SC series cylinders;
7. Utilizes high-temperature resistant sealing compounds for operational range of 0-150°C.
Category: Standard Cylinders | Brand: AIRTAC® | Series: SAU
AirTAC SAU Standard Cylinder SAU32X105 Technical Details
- Model: SAU32X105
- Bore size: 32mm
- Stroke: 105mm
- Operating pressure: 0.1–0.9 MPa
- Cushion type: Adjustable air cushion (both ends)
- Mounting style: Basic type (MF1), optional front flange (MP4) or rear clevis (M3)
- Piston rod material: Chrome-plated stainless steel (SUS304)
- Cylinder tube: Hard anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Port size: G1/8 (M14×1.5 optional)
- Ambient temperature: -20℃ to 80℃
- Weight: 1.85kg (without accessories)
- Dimensions: 293mm(L) × 50mm(W) × 50mm(H) (at mid-stroke position)
- Max theoretical thrust: 723N @0.63MPa
- Speed range: 50–800mm/s
- Protection rating: IP65 (with wiper seal)
- ISO standard: 6432
High-precision industrial cylinder featuring wear-resistant construction and dual cushioning adjustment. The SAU32X105 combines smooth operation with 0.1mm repeat positioning accuracy, utilizing a chromium-plated piston rod with integrated scraper to prevent contamination ingress. Requires ISO VG32 or equivalent hydraulic oil lubrication for optimal performance.
- Automated assembly line clamping mechanisms
- Plastic injection molding machine ejectors
- CNC machine tool workpiece positioning
- Packaging equipment pusher systems
- Automotive welding fixture actuators
Installation guidelines:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, use M3 clevis type with safety nut. Lubricate through
air supply (ISO VG32 oil mist) at 1-2 drops/minute for maintenance-free operation.
| Property | Property Value |
|---|---|
| sku | SAU32X105 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 105mm |
