Airtac SAU Standard Air Cylinder SAU32X115
2. Features asymmetric bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir functionality;
3. Constructed with octagonal aluminum tubing (non-tie-rod design), offering enhanced corrosion resistance. Equipped with built-in sensor mounting grooves for simplified installations;
4. Compact stroke length compared to ISO 15662 compliant cylinders of equivalent bore sizes in SAU series;
5. Incorporates adjustable cushioning mechanism for smooth end-of-stroke deceleration;
6. Shares universal mounting accessories compatibility with SC series cylinders;
7. Utilizes high-temperature resistant sealing compounds for operational range of 0-150°C.
Category: Standard Cylinders | Brand: AIRTAC® | Series: SAU
AirTAC SAU Standard Cylinder SAU32X115 Technical Details
- Model: SAU32X115
- Bore size: 32mm
- Stroke: 115mm
- Operating pressure: 0.1-0.9 MPa
- Cushion type: Adjustable air cushion (both ends)
- Mounting style: Basic type (MF1), optional front flange (MP4), rear flange (MP5), or foot mounting (M3)
- Port size: M5x0.8 (G1/8 adapter available)
- Piston rod thread: M14x1.5
- Ambient temperature: -20℃ to 80℃
- Material:
- Cylinder tube: Aluminum alloy with hard anodization
- Piston rod: Chrome-plated stainless steel (SUS304)
- Seals: NBR (Nitrile rubber)
- Weight: 0.92kg (excluding accessories)
- Dimensions:
- Total length: 195mm (stroke 115 + 40mm x2 end caps)
- External diameter: 32mm ±0.5mm
- Mounting width: 38mm (basic type)
- Rod end to base: 153mm (extended position)
High-precision ISO 15552 compliant pneumatic cylinder featuring wear-resistant construction and dual cushioning adjustment. The SAU32X115's chromium-plated rod and integrated scraper seal provide exceptional contamination resistance, making it ideal for high-cycle applications. Requires ISO VG32 or equivalent hydraulic oil mist lubrication (0.3-0.5cc/min recommended).
- Automated assembly line clamping mechanisms
- Plastic injection molding ejector systems
- CNC machine tool door actuators
- Food processing conveyor gate controls
- Automotive welding fixture positioning
Installation guidelines:
Maximum side load ≤15% of thrust rating. For vertical mounting,
use counterbalance valves when holding loads. Lubricator oil viscosity
should maintain ISO VG32 at 40℃. Allow 20mm clearance for cushion sleeve adjustment.
| Property | Property Value |
|---|---|
| sku | SAU32X115 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 115mm |
