Airtac SAU Standard Air Cylinder SAU32X275
2. Features asymmetric bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir functionality;
3. Constructed with octagonal aluminum tubing (non-tie-rod design), offering enhanced corrosion resistance. Equipped with built-in sensor mounting grooves for simplified installations;
4. Compact stroke length compared to ISO 15662 compliant cylinders of equivalent bore sizes in SAU series;
5. Incorporates adjustable cushioning mechanism for smooth end-of-stroke deceleration;
6. Shares universal mounting accessories compatibility with SC series cylinders;
7. Utilizes high-temperature resistant sealing compounds for operational range of 0-150°C.
Category: Standard Cylinders | Brand: AIRTAC® | Series: SAU
AirTAC SAU Standard Cylinder SAU32X275 Technical Specifications
- Basic Specifications:
- Model: SAU32X275
- Type: ISO 6432 compliant double-acting cylinder
- Bore size: 32mm (±0.1mm tolerance)
- Stroke: 275mm (adjustable ±1mm)
- Operating pressure: 0.15-1.0 MPa
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Temperature range: -20℃ to +80℃
- Port size: G1/4 (BSPP thread)
- Piston rod thread: M16x1.5 (ISO 12240-1 standard)
- Mounting type: Basic series (MF style) with optional accessories
- Physical Properties:
- Weight: 2.4kg (excluding accessories)
- Extended length: 375mm (stroke + end caps)
- Body diameter: 42mm (cylinder tube OD)
- Rod diameter: 12mm (chrome-plated steel)
- Stroke tolerance: ±1.5mm
High-precision industrial cylinder featuring wear-resistant aluminum alloy tube (Al-Mg-Si series) with hard anodized surface treatment. Integrated magnetizable piston enables position sensing compatibility. The dual sealing system combines HNBR for dynamic parts and FKM for static seals, ensuring ≤0.5mm/s leakage rate at 0.5MPa. Includes anti-rotation guide for precise linear motion.
- Automated production line material handling
- Packaging machine clamp positioning
- CNC machine tool fixture actuation
- Automotive welding jig operation
- Pharmaceutical bottling line controls
Installation guidelines:1. Maintain 0.5-1mm alignment tolerance during mounting
2. Lubricate with ISO VG32 hydraulic oil (1-2 drops per port)
3. Maximum side load: 15N at mid-stroke position
4. Recommend 100μm filtration for optimal seal life
| Property | Property Value |
|---|---|
| sku | SAU32X275 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 275mm |
