Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100-10A
The AirTAC Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100-10A is a genuine double-acting profile-type cylinder with a Ø100mm bore, 100mm stroke and a built-in 4M310-10 5/2 solenoid valve — it switches itself from one coil signal, so no separate remote valve or extra plumbing is needed.
- BoreØ100 mm
- Stroke100 mm
- Built-in valve4M310-10
- Valve port3/8"
- CoilAC220V
- EntryTerminal
About the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100-10A
The AirTAC SAUF100X100-10A is a double-acting profile cylinder with a built-in 4M310 5/2 solenoid valve on the cap. One coil signal directly switches the actuator, eliminating remote plumbing and saving a manifold slot in decentralized setups. The extruded aluminum barrel makes it shorter than a standard ISO 15552 unit of the same bore.
It features a 100mm bore, 1/2" cylinder port, and a 3/8" valve port. The integrated valve delivers a 30 mm2 flow (Cv 1.68) and cycles up to 4 times per second. The cylinder body rates to 1.0 MPa, but you must size force within the valve's 0.15-0.8 MPa operating window. At 0.5 MPa it pushes 3927 N and pulls 3681 N. For reliable sizing, figure a safe working load of roughly 2356 N, which handles a vertical lift of about 200 kg with a 2:1 margin.
Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100-10A Technical Specifications
| Model | Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100-10A |
|---|---|
| Series | SAUF profile cylinder with valve |
| Bore size | Ø100 mm |
| Stroke | 100 mm |
| Acting type | Double acting, self-valved |
| Cylinder port | 1/2" |
| Rod thread | M20×1.5 |
| PU tube | Ø10 × Ø6.5 |
| Built-in valve | 4M310-10 (5/2) |
|---|---|
| Valve flow | 30.0 mm² (Cv 1.68) |
| Max frequency | 4 cycle/sec |
| Coil voltage | AC220V · AC 3.5 VA |
| Electrical entry | Terminal · IP65 · B class |
| Response time | 0.05 s and below |
| Operating pressure | 0.15 – 0.8 MPa (valve limit) |
| Speed range | 30 – 800 mm/s |
The cylinder rates to 1.0 MPa but the built-in valve operates 0.15–0.8 MPa, so run the assembled SAUF at 0.15–0.8 MPa. Default: rod retracts when the coil is energised (reconfigurable to extend). Specs follow the official AirTAC SAUF datasheet. Port options: PT / G.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
Sized within the valve's 0.15–0.8 MPa range. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100-10A
| SAUF | Profile cylinder with built-in 4M valve. |
|---|---|
| 100×100 | Bore × stroke in mm. |
| -10 | Valve port 3/8" → 4M310-10. |
| A | Coil voltage AC220V. |
| I / (blank) | Terminal electrical entry. |
SAUF does not hold its load without air — the valve routes air, it is not a lock. For a held load, add an external rod lock or a pilot-operated check valve.
Where the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100-10A Is Used
Heavy-Duty Clamp Stations
Decentralized clamping on large machining lines where running a 100mm bore actuator from a central manifold wastes tubing.
Automated Press Systems
Independent pressing circuits using the built-in 4M310 valve to deliver 6282 N force at 0.8 MPa without extra plumbing.
Pallet Diverter Gates
Direct actuation of heavy diverters on packaging conveyors, saving manifold space by switching locally via one AC220V signal.
Is the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100-10A the Right Choice?
When sizing, compare against the 80mm bore (push 2513 N at 0.5 MPa) and the 100mm bore (push 3927 N at 0.5 MPa) to match your load within the 0.15-0.8 MPa valve limit. This AC220V terminal entry coil offers IP65 protection. Default action retracts the rod when energized, but you can reposition the valve to extend on signal. Because this SKU lacks the S magnet suffix, it cannot accept magnetic switches. The valve only routes air, so add an external rod lock or pilot-operated check valve to hold loads safely. For this 100mm stroke side loads are minimal, but always guide rods on strokes of 300mm or more.
Quick checklist
- ✓ Force at 0.15–0.8 MPa
- ✓ Coil voltage matches panel
- ✓ Terminal vs grommet entry
- ✓ Retract- or extend-when-energised
- ✓ Load-holding → external rod lock
Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100-10A FAQ
It generates 3927 N push and 3681 N pull at 0.5 MPa, reaching 6282 N at 0.8 MPa. The built-in valve is a 4M310-10 (3/8" port, Cv 1.68, 30 mm2 flow) running on AC220V. Although the cylinder body rates to 1.0 MPa, the assembled unit operates strictly within the 0.15-0.8 MPa valve window.
No. The built-in 5/2 valve routes air but does not lock the piston. If air is lost, the load drifts. For vertical holding, install an external rod lock or pilot-operated check valve. The default action retracts the rod when energized, but you can reposition the valve to extend on signal.
