Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100-10B
The AirTAC Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100-10B is a genuine double-acting profile-type cylinder with a Ø100mm bore, 100mm stroke and a built-in 4M310-10 5/2 solenoid valve — it switches itself from one coil signal, so no separate remote valve or extra plumbing is needed.
- BoreØ100 mm
- Stroke100 mm
- Built-in valve4M310-10
- Valve port3/8"
- CoilDC24V
- EntryTerminal
About the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100-10B
The SAUF100X100-10B is a double-acting profile cylinder with a built-in AirTAC 4M310 5/2 solenoid valve on the cap. One coil signal drives the actuator, eliminating remote plumbing and saving a manifold slot. The extruded aluminum barrel is shorter than an ISO 15552 unit of the same bore. This 100mm bore uses a 1/2" cylinder port and delivers 3927N push at 0.5MPa.
The integrated 4M310-10 valve has a 3/8" port, Cv 1.68 flow, and cycles up to 4 times per second. The DC24V terminal coil offers IP65 protection and a 0.05s response. Size force within the 0.15-0.8MPa valve window. Based on the 3927N push at 0.5MPa, the safe working load is roughly 2356N, translating to a 200kg vertical lift with a 2:1 margin.
Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100-10B Technical Specifications
| Model | Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100-10B |
|---|---|
| Series | SAUF profile cylinder with valve |
| Bore size | Ø100 mm |
| Stroke | 100 mm |
| Acting type | Double acting, self-valved |
| Cylinder port | 1/2" |
| Rod thread | M20×1.5 |
| PU tube | Ø10 × Ø6.5 |
| Built-in valve | 4M310-10 (5/2) |
|---|---|
| Valve flow | 30.0 mm² (Cv 1.68) |
| Max frequency | 4 cycle/sec |
| Coil voltage | DC24V · DC 3.0 W |
| Electrical entry | Terminal · IP65 · B class |
| Response time | 0.05 s and below |
| Operating pressure | 0.15 – 0.8 MPa (valve limit) |
| Speed range | 30 – 800 mm/s |
The cylinder rates to 1.0 MPa but the built-in valve operates 0.15–0.8 MPa, so run the assembled SAUF at 0.15–0.8 MPa. Default: rod retracts when the coil is energised (reconfigurable to extend). Specs follow the official AirTAC SAUF datasheet. Port options: PT / G.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
Sized within the valve's 0.15–0.8 MPa range. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100-10B
| SAUF | Profile cylinder with built-in 4M valve. |
|---|---|
| 100×100 | Bore × stroke in mm. |
| -10 | Valve port 3/8" → 4M310-10. |
| B | Coil voltage DC24V. |
| I / (blank) | Terminal electrical entry. |
SAUF does not hold its load without air — the valve routes air, it is not a lock. For a held load, add an external rod lock or a pilot-operated check valve.
Where the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100-10B Is Used
Decentralized Press Clamps
Actuate large clamping jaws directly at the press station without routing long tube runs back to a central manifold.
Inline Diverters
Switch heavy diverter arms on a high-speed packaging line using one DC24V signal per actuator.
Pallet Lift Stations
Lift loaded pallets in independent zones, leveraging the 200kg vertical lift capacity safely.
Is the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100-10B the Right Choice?
This 100mm bore provides 3927N push at 0.5MPa; step down to an 80mm bore for 2513N, or up if more force is needed. The stroke is 100mm, above the 75mm minimum for this bore. Confirm the DC24V terminal entry and PT thread meet your electrical standards. The default action retracts the rod when energised, but you can reposition the valve to extend on signal. Because the valve routes air, it is not a load lock; add an external rod lock or pilot-operated check valve to hold a load. For strokes of 300mm or more, use SC-series mounts and guide the side load.
Quick checklist
- ✓ Force at 0.15–0.8 MPa
- ✓ Coil voltage matches panel
- ✓ Terminal vs grommet entry
- ✓ Retract- or extend-when-energised
- ✓ Load-holding → external rod lock
Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100-10B FAQ
It pushes 3927N and pulls 3681N at 0.5MPa, using a built-in 4M310-10 valve with Cv 1.68 and a 3/8" port. The DC24V coil operates at 0.15-0.8MPa; never size the assembled unit above 0.8MPa even though the cylinder body rates to 1.0MPa.
This SKU lacks the S suffix for a magnet, so it cannot take a magnetic switch. The default action retracts the rod when the coil energises; you can reposition the valve to extend on signal instead.
