Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000-08A
1、Engineered as a derivative series integrating standard cylinders with valves, compatible with 4M210 (for 32mm, 40mm, 50mm bores) and 4M310 valves (for 63mm, 80mm, 100mm bores).
2、Enables direct one-to-one pneumatic control without external valve installation.
3、Optimizes spatial efficiency and installation time, ideal for decentralized configurations in large-scale systems.
4、Supports multiple standardized mounting accessories for simplified integration.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SAUF
AirTAC SAUF Series Integrated Valve Cylinder SAUF100X1000-08A Specifications
- Model: SAUF100X1000-08A
- Type: Compact valve-cylinder combination (Double-acting with built-in 5/2-way solenoid valve)
- Bore size: Ø100 mm
- Stroke: 1000 mm
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Port size: G3/8 (NPT1/2 optional)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response time: ≤50 ms (at 0.5 MPa)
- Ambient temperature: -10℃ to 60℃ (No freeze)
- Weight: 12.8 kg (excluding accessories)
- Dimensions: 1180mm(L) × 142mm(W) × 142mm(H) (Fully extended)
- Body material: Aluminum alloy (Surface anodized)
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP67 (Dust-tight & protected against immersion)
- Lubrication: Pre-lubricated (Use ISO VG32 turbine oil if re-lubrication needed)
Integrated pneumatic actuator combining cylinder and valve in a space-saving package, designed for heavy-duty pushing/pulling operations requiring centralized control. Features a built-in high-flow 5/2-way solenoid valve with manual override and status indicator. The reinforced piston rod (Cr-Mo steel, hard chrome plated) ensures durability in high-moment applications.
- Press machine ejection systems
- Automotive welding fixture clamping
- Large-scale packaging equipment pushers
- Foundry mold clamping mechanisms
- Heavy conveyor gate controls
Installation guidelines: Mount horizontally using 4x M10 mounting bolts (not included). Maintain minimum 50mm clearance around valve section for heat dissipation. Install downstream filter (5μm) with auto-drain. Lubricator recommended for >1 million cycle operations. Avoid side load exceeding 200N on piston rod.| Property | Property Value |
|---|---|
| sku | SAUF100X1000-08A |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Standard Voltage | AC220V |
| Solenoid Valve Model | 4M Series, 31mm Bore, 80mm Stroke, M9W Sensor |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
