Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000-10B
The AirTAC Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000-10B is a genuine double-acting profile-type cylinder with a Ø100mm bore, 1000mm stroke and a built-in 4M310-10 5/2 solenoid valve — it switches itself from one coil signal, so no separate remote valve or extra plumbing is needed.
- BoreØ100 mm
- Stroke1000 mm
- Built-in valve4M310-10
- Valve port3/8"
- CoilDC24V
- EntryTerminal
About the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000-10B
The SAUF100X1000-10B is a double-acting profile cylinder with a built-in AirTAC 4M310 5/2 solenoid valve on the cap. One coil signal drives the cylinder, eliminating remote valves and saving a manifold slot. The extruded aluminum barrel is shorter than an ISO 15552 cylinder of the same bore. It features a 1000 mm stroke, a 1/2" cylinder port, and an M20x1.5 rod thread.
Driven by a DC24V coil with terminal entry, the integrated valve has a 3/8" port, Cv 1.68, and runs at up to 4 cycles per second. The cylinder body rates to 1.0 MPa, but you must size force within the valve's 0.15-0.8 MPa working window. At 0.5 MPa it pushes 3927 N. The safe working load is roughly 2356 N, allowing a vertical lift of about 200 kg with a 2:1 margin. This SKU lacks a magnet, so it cannot take a magnetic switch.
Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000-10B Technical Specifications
| Model | Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000-10B |
|---|---|
| Series | SAUF profile cylinder with valve |
| Bore size | Ø100 mm |
| Stroke | 1000 mm |
| Acting type | Double acting, self-valved |
| Cylinder port | 1/2" |
| Rod thread | M20×1.5 |
| PU tube | Ø10 × Ø6.5 |
| Built-in valve | 4M310-10 (5/2) |
|---|---|
| Valve flow | 30.0 mm² (Cv 1.68) |
| Max frequency | 4 cycle/sec |
| Coil voltage | DC24V · DC 3.0 W |
| Electrical entry | Terminal · IP65 · B class |
| Response time | 0.05 s and below |
| Operating pressure | 0.15 – 0.8 MPa (valve limit) |
| Speed range | 30 – 800 mm/s |
The cylinder rates to 1.0 MPa but the built-in valve operates 0.15–0.8 MPa, so run the assembled SAUF at 0.15–0.8 MPa. Default: rod retracts when the coil is energised (reconfigurable to extend). Specs follow the official AirTAC SAUF datasheet. Port options: PT / G.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
Sized within the valve's 0.15–0.8 MPa range. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000-10B
| SAUF | Profile cylinder with built-in 4M valve. |
|---|---|
| 100×1000 | Bore × stroke in mm. |
| -10 | Valve port 3/8" → 4M310-10. |
| B | Coil voltage DC24V. |
| I / (blank) | Terminal electrical entry. |
SAUF does not hold its load without air — the valve routes air, it is not a lock. For a held load, add an external rod lock or a pilot-operated check valve.
Where the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000-10B Is Used
Decentralized Pallet Diverter
Uses the built-in valve to actuate a 1000 mm diverter arm directly at the conveyor, eliminating long tubing runs back to a central manifold.
Autonomous Lift Gate
Provides heavy vertical lifting in a storage system. The integrated DC24V valve simplifies wiring while delivering 3927 N of push force at 0.5 MPa.
Machine Guard Door
Cycles a large safety door on a packaging line. The 4M310 valve handles 4 cycles per second, and the profile body fits tight machine frames.
Is the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000-10B the Right Choice?
For a 1000 mm stroke, size between the 80 mm bore (2513 N push at 0.5 MPa) and this 100 mm bore (3927 N push at 0.5 MPa). Confirm the DC24V terminal coil and 3/8" valve port meet your supply. The rod retracts when energised by default, but you can reposition the valve to extend on signal. Keep operating pressure within 0.15-0.8 MPa. The valve routes air and is not a lock; add an external rod lock or pilot-operated check valve to hold a load. At 1000 mm, use an external guide to prevent rod bending and side-load wear.
Quick checklist
- ✓ Force at 0.15–0.8 MPa
- ✓ Coil voltage matches panel
- ✓ Terminal vs grommet entry
- ✓ Retract- or extend-when-energised
- ✓ Load-holding → external rod lock
Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000-10B FAQ
It generates 3927 N push and 3681 N pull at 0.5 MPa, reaching 6282 N at 0.8 MPa. The built-in valve is a 4M310-10 (3/8" port, Cv 1.68) running on DC24V. Although the cylinder body rates to 1.0 MPa, the assembled unit must operate within the valve's 0.15-0.8 MPa range.
No, the 5/2 valve only routes air and is not a load lock; the piston will drift on air loss. Add an external rod lock or pilot-operated check valve for holding. By default the rod retracts when the coil is energised, but you can reposition the valve to extend on signal.
