Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-08A
2、Enables direct one-to-one pneumatic control without external valve installation.
3、Optimizes spatial efficiency and installation time, ideal for decentralized configurations in large-scale systems.
4、Supports multiple standardized mounting accessories for simplified integration.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SAUF
AirTAC SAUF Series Valve-Integrated Cylinder SAUF100X1000S-08A Specifications
- Model: SAUF100X1000S-08A
- Type: Double-acting cylinder with integrated 5/2-way solenoid valve
- Bore size: Ø100 mm
- Stroke: 1000 mm (±0.5 mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: PT1/4 (G1/4 optional)
- Valve voltage: DC24V/AC110V/AC220V (selectable)
- Weight: 24.8 kg (without accessories)
- Dimensions: 1215mm(L) × 135mm(W) × 135mm(H)
- Rod thread: M20×1.5
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal material: NBR (standard)/PU (optional)
- Temperature range: -10℃ to 80℃
- Response time: ≤0.1s (valve switching)
- Protection rating: IP67 (valve section)
High-force integrated cylinder-valve unit designed for heavy-duty linear motion applications. Features space-saving valve mounting with direct air passage design reducing pressure loss by 15% compared to separate components. The triple-sealed piston rod withstands side loads up to 300N lateral force.
- Press machine ejection systems
- Automotive welding fixture clamping
- Large conveyor gate controls
- Construction equipment actuators
- Plastic injection molding machines
Installation note:
Mount valve section vertically upward to prevent debris accumulation.
Use rigid mounting brackets at both ends for strokes >800mm.
Allow 50mm clearance around valve for heat dissipation.
| Property | Property Value |
|---|---|
| sku | SAUF100X1000S-08A |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Standard Voltage | AC220V |
| Solenoid Valve Model | 4M Series, 31mm Bore, 80mm Stroke, M9W Sensor |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
