Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-08A
The AirTAC Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-08A is a genuine double-acting profile-type cylinder with a Ø100mm bore, 1000mm stroke and a built-in 4M310-08 5/2 solenoid valve — it switches itself from one coil signal, so no separate remote valve or extra plumbing is needed.
- BoreØ100 mm
- Stroke1000 mm
- Built-in valve4M310-08
- Valve port1/4"
- CoilAC220V
- EntryTerminal
About the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-08A
The SAUF100X1000S-08A is a double-acting profile cylinder with a built-in AirTAC 4M310 5/2 solenoid valve on the cap. One coil signal drives the actuator, eliminating remote plumbing and saving a manifold slot. The 100mm bore delivers 3927N push and 3681N pull at 0.5MPa, operating safely within the valve's 0.15-0.8MPa range. It features a 1/2" cylinder port and a 1/4" valve port.
This unit includes a piston magnet for position sensing and switches at up to 4 cycles per second. The integrated valve offers a Cv of 1.4 and uses a terminal entry AC220V coil. For sizing, the safe working load is roughly 2356N, allowing a vertical lift of about 200kg with a 2:1 margin.
Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-08A Technical Specifications
| Model | Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-08A |
|---|---|
| Series | SAUF profile cylinder with valve |
| Bore size | Ø100 mm |
| Stroke | 1000 mm |
| Acting type | Double acting, self-valved |
| Cylinder port | 1/2" |
| Rod thread | M20×1.5 |
| PU tube | Ø10 × Ø6.5 |
| Built-in valve | 4M310-08 (5/2) |
|---|---|
| Valve flow | 25.0 mm² (Cv 1.40) |
| Max frequency | 4 cycle/sec |
| Coil voltage | AC220V · AC 3.5 VA |
| Electrical entry | Terminal · IP65 · B class |
| Response time | 0.05 s and below |
| Operating pressure | 0.15 – 0.8 MPa (valve limit) |
| Speed range | 30 – 800 mm/s |
The cylinder rates to 1.0 MPa but the built-in valve operates 0.15–0.8 MPa, so run the assembled SAUF at 0.15–0.8 MPa. Default: rod retracts when the coil is energised (reconfigurable to extend). Specs follow the official AirTAC SAUF datasheet. Port options: PT / G.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
Sized within the valve's 0.15–0.8 MPa range. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-08A
| SAUF | Profile cylinder with built-in 4M valve. |
|---|---|
| 100×1000 | Bore × stroke in mm. |
| -08 | Valve port 1/4" → 4M310-08. |
| A | Coil voltage AC220V. |
| I / (blank) | Terminal electrical entry. |
SAUF does not hold its load without air — the valve routes air, it is not a lock. For a held load, add an external rod lock or a pilot-operated check valve.
Where the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-08A Is Used
Decentralized Press Clamping
Clamp heavy parts directly at the press station using one coil signal, bypassing a central manifold for faster response.
Long-Stroke Diverters
Actuate 1000mm diverting gates on high-speed lines without routing long tubing runs back to a main valve bank.
Vertical Material Lifts
Lift 200kg loads vertically with a 2:1 safety margin, using the built-in magnet to confirm endpoints.
Is the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-08A the Right Choice?
Size this 100mm bore against the 80mm option, comparing your required force to the 3927N push at 0.5MPa. Verify the AC220V terminal entry and PT threads match your supply. The rod retracts when energised but can be reconfigured to extend by repositioning the valve. Always size force within the 0.15-0.8MPa valve window, not the 1.0MPa cylinder body rating. The valve routes air and is not a lock; add an external rod lock or pilot-operated check valve to hold loads. For the 1000mm stroke, use external guides to prevent rod bending and side loads.
Quick checklist
- ✓ Force at 0.15–0.8 MPa
- ✓ Coil voltage matches panel
- ✓ Terminal vs grommet entry
- ✓ Retract- or extend-when-energised
- ✓ Load-holding → external rod lock
Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-08A FAQ
It pushes 3927N and pulls 3681N at 0.5MPa. The built-in 4M310-08 valve has a 1/4" port, Cv of 1.4, and runs on AC220V. Size the force within the valve's 0.15-0.8MPa operating window, as the assembled unit cannot use the 1.0MPa cylinder body rating.
Yes. The default action retracts the rod when energised, but you can reposition the valve to extend the rod on signal. This self-switching design removes the need for a remote valve while maintaining full 5/2 control.
