Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-08B
2、Enables direct one-to-one pneumatic control without external valve installation.
3、Optimizes spatial efficiency and installation time, ideal for decentralized configurations in large-scale systems.
4、Supports multiple standardized mounting accessories for simplified integration.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SAUF
AirTAC SAUF Series Valve-Integrated Cylinder SAUF100X1000S-08B Technical Details
- Full model code: SAUF100X1000S-08B
- Type: ISO 15552 compliant cylinder with integrated 5/2-way solenoid valve
- Bore size: Ø100mm (3.94")
- Stroke length: 1000mm (39.37")
- Operating pressure: 0.1–0.9 MPa (14.5–130.5 PSI)
- Medium temperature: -20℃ to 80℃ (-4°F to 176°F)
- Cushioning type: Adjustable pneumatic cushion at both ends
- Valve configuration: Single solenoid with spring return (5/2-way)
- Voltage variants: DC24V (±10%) / AC110V (50/60Hz) / AC220V (50/60Hz)
- Port size: G3/8 (Rc3/8) for air connections
- Speed control: Built-in flow control valve (0.1–1.5 m/s adjustable)
- Protection class: IP67 (dust tight & temporary immersion protected)
- Material: Aluminum alloy cylinder tube, chrome-plated piston rod
- Weight: 24.8kg (54.7 lbs) ±5%
- Dimensions: 1180mm(L) × 200mm(W) × 200mm(H) (46.46" × 7.87" × 7.87")
High-force pneumatic actuator combining cylinder and valve in one unit, engineered for heavy-duty industrial applications requiring extended stroke precision. Features corrosion-resistant construction with double-seal piston design for leak-free operation. Integrated silencer reduces exhaust noise to ≤72dB(A). Requires ISO 8573-1:2010 Class 3-4-3 compressed air quality.
- Automotive production line clamping systems
- Steel coil handling equipment in metal processing
- Large-format injection molding machine ejectors
- Paper roll positioning in printing machinery
- Shipbuilding jig alignment systems
Maintenance protocol:
Lubricate piston rod weekly with ISO VG32 hydraulic oil.
Avoid lateral force exceeding 150N during operation.
For vertical mounting, install auxiliary support brackets.
| Property | Property Value |
|---|---|
| sku | SAUF100X1000S-08B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Standard Voltage | DC24V |
| Solenoid Valve Model | 4M Series, 31mm Bore, 80mm Stroke, M9W Sensor |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
