Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-10A
The AirTAC Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-10A is a genuine double-acting profile-type cylinder with a Ø100mm bore, 1000mm stroke and a built-in 4M310-10 5/2 solenoid valve — it switches itself from one coil signal, so no separate remote valve or extra plumbing is needed.
- BoreØ100 mm
- Stroke1000 mm
- Built-in valve4M310-10
- Valve port3/8"
- CoilAC220V
- EntryTerminal
About the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-10A
The SAUF100X1000S-10A is a double-acting profile cylinder with a built-in AirTAC 4M310 5/2 solenoid valve on the cap. One coil signal drives the actuator, eliminating remote plumbing and saving a manifold slot. The extruded aluminum barrel makes it shorter than an ISO 15552 cylinder of the same bore. This 100mm bore version uses a 1/2" cylinder port and a 3/8" valve port. It includes a piston magnet for CMSG/DMSG/EMSG switches.
The integrated valve delivers a 30 mm2 flow (Cv 1.68) and cycles up to 4 times per second. The cylinder body rates to 1.0 MPa, but the assembled unit operates strictly within the 0.15-0.8 MPa valve window. At 0.5 MPa it pushes 3927 N and pulls 3681 N. For sizing, the safe working load is roughly 2356 N, and it can vertically lift about 200 kg with a 2:1 margin. The AC220V terminal coil is IP65 rated.
Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-10A Technical Specifications
| Model | Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-10A |
|---|---|
| Series | SAUF profile cylinder with valve |
| Bore size | Ø100 mm |
| Stroke | 1000 mm |
| Acting type | Double acting, self-valved |
| Cylinder port | 1/2" |
| Rod thread | M20×1.5 |
| PU tube | Ø10 × Ø6.5 |
| Built-in valve | 4M310-10 (5/2) |
|---|---|
| Valve flow | 30.0 mm² (Cv 1.68) |
| Max frequency | 4 cycle/sec |
| Coil voltage | AC220V · AC 3.5 VA |
| Electrical entry | Terminal · IP65 · B class |
| Response time | 0.05 s and below |
| Operating pressure | 0.15 – 0.8 MPa (valve limit) |
| Speed range | 30 – 800 mm/s |
The cylinder rates to 1.0 MPa but the built-in valve operates 0.15–0.8 MPa, so run the assembled SAUF at 0.15–0.8 MPa. Default: rod retracts when the coil is energised (reconfigurable to extend). Specs follow the official AirTAC SAUF datasheet. Port options: PT / G.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
Sized within the valve's 0.15–0.8 MPa range. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-10A
| SAUF | Profile cylinder with built-in 4M valve. |
|---|---|
| 100×1000 | Bore × stroke in mm. |
| -10 | Valve port 3/8" → 4M310-10. |
| A | Coil voltage AC220V. |
| I / (blank) | Terminal electrical entry. |
SAUF does not hold its load without air — the valve routes air, it is not a lock. For a held load, add an external rod lock or a pilot-operated check valve.
Where the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-10A Is Used
Decentralized Press Clamps
Ideal for large presses where running individual air lines to a central manifold is impractical, letting each clamp switch itself locally.
Independent Divert Gates
Perfect for long conveyor lines where each divert gate needs its own actuation signal without consuming manifold slots.
Vertical Lift Stations
Handles vertical lifts up to 200kg with a 2:1 safety margin at 0.5 MPa, integrating the valve directly on the cap to save space.
Is the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-10A the Right Choice?
When sizing, compare neighboring bores: the 80mm bore offers 2513 N push at 0.5 MPa, while this 100mm bore provides 3927 N. Confirm your coil is AC220V with terminal entry before ordering. The default action retracts the rod when energized, but you can reposition the valve to extend on signal. Always size force within the 0.15-0.8 MPa valve range, never the 1.0 MPa cylinder body rating. The valve only routes air; it is not a lock, so add an external rod lock or pilot-operated check valve to hold a load. Because the 1000mm stroke exceeds 300mm, use external guides to prevent rod bending and side-load damage.
Quick checklist
- ✓ Force at 0.15–0.8 MPa
- ✓ Coil voltage matches panel
- ✓ Terminal vs grommet entry
- ✓ Retract- or extend-when-energised
- ✓ Load-holding → external rod lock
Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-10A FAQ
It pushes 3927 N and pulls 3681 N at 0.5 MPa, reaching 6282 N at 0.8 MPa. The built-in valve is a 4M310-10 (3/8" port, Cv 1.68, max 4 cycles/sec). The cylinder body rates to 1.0 MPa, but you must size force within the assembled valve's 0.15-0.8 MPa operating window. The coil is AC220V with terminal entry.
Yes. The default action retracts the rod when energized, but you can reposition the built-in valve to make the rod extend on signal. This self-switching capability means you need no remote valve, saving tubing and installation time across decentralized machine stations.
