Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-10B
The AirTAC Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-10B is a genuine double-acting profile-type cylinder with a Ø100mm bore, 1000mm stroke and a built-in 4M310-10 5/2 solenoid valve — it switches itself from one coil signal, so no separate remote valve or extra plumbing is needed.
- BoreØ100 mm
- Stroke1000 mm
- Built-in valve4M310-10
- Valve port3/8"
- CoilDC24V
- EntryTerminal
About the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-10B
The SAUF100X1000S-10B is a double-acting profile cylinder with a built-in AirTAC 4M310-10 5/2 solenoid valve on the cap. One coil signal drives the actuator, eliminating remote plumbing and saving a manifold slot. The extruded aluminum barrel makes it shorter than an ISO 15552 unit of the same bore. It features a piston magnet for switches and a 1/2 inch cylinder port.
Operating within the valve's 0.15-0.8 MPa window, it delivers 3927 N push force at 0.5 MPa. A practical computed insight: safe working load is roughly 2356 N (about 60% of the 0.5 MPa figure), allowing a vertical lift of approximately 200 kg with a 2:1 margin. The integrated valve provides 30 mm2 flow (Cv 1.68) with a 4 cycle/s limit, and the DC24V terminal coil offers IP65 protection.
Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-10B Technical Specifications
| Model | Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-10B |
|---|---|
| Series | SAUF profile cylinder with valve |
| Bore size | Ø100 mm |
| Stroke | 1000 mm |
| Acting type | Double acting, self-valved |
| Cylinder port | 1/2" |
| Rod thread | M20×1.5 |
| PU tube | Ø10 × Ø6.5 |
| Built-in valve | 4M310-10 (5/2) |
|---|---|
| Valve flow | 30.0 mm² (Cv 1.68) |
| Max frequency | 4 cycle/sec |
| Coil voltage | DC24V · DC 3.0 W |
| Electrical entry | Terminal · IP65 · B class |
| Response time | 0.05 s and below |
| Operating pressure | 0.15 – 0.8 MPa (valve limit) |
| Speed range | 30 – 800 mm/s |
The cylinder rates to 1.0 MPa but the built-in valve operates 0.15–0.8 MPa, so run the assembled SAUF at 0.15–0.8 MPa. Default: rod retracts when the coil is energised (reconfigurable to extend). Specs follow the official AirTAC SAUF datasheet. Port options: PT / G.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
Sized within the valve's 0.15–0.8 MPa range. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-10B
| SAUF | Profile cylinder with built-in 4M valve. |
|---|---|
| 100×1000 | Bore × stroke in mm. |
| -10 | Valve port 3/8" → 4M310-10. |
| B | Coil voltage DC24V. |
| I / (blank) | Terminal electrical entry. |
SAUF does not hold its load without air — the valve routes air, it is not a lock. For a held load, add an external rod lock or a pilot-operated check valve.
Where the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-10B Is Used
Heavy Press Station
Decentralized pressing on a large assembly line. The built-in 4M310-10 valve handles the 100 mm bore directly, saving manifold space while delivering 3927 N at 0.5 MPa.
Vertical Material Lift
Lifting heavy pallets where a remote valve would require long tubing runs. The integrated valve responds in under 0.05 s, and the magnet allows precise end-position sensing.
Long-Stroke Diversion
Diverting heavy products across a wide conveyor. The 1000 mm stroke requires external guides, while the one-signal switching simplifies machine wiring.
Is the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-10B the Right Choice?
When sizing, compare neighboring bores: the 80 mm bore yields 2513 N push at 0.5 MPa, while this 100 mm bore provides 3927 N. Always confirm the DC24V terminal entry and PT thread match your control setup. The cylinder body rates to 1.0 MPa, but you must size force within the 0.15-0.8 MPa valve window. By default the rod retracts when energized, but repositioning the valve switches it to extend-when-energized. The valve only routes air, so add an external rod lock or pilot-operated check valve to hold loads. For this 1000 mm stroke, use external guides to prevent rod bending and side loads.
Quick checklist
- ✓ Force at 0.15–0.8 MPa
- ✓ Coil voltage matches panel
- ✓ Terminal vs grommet entry
- ✓ Retract- or extend-when-energised
- ✓ Load-holding → external rod lock
Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-10B FAQ
It uses a built-in 4M310-10 valve (3/8 inch port, Cv 1.68, 4 cycles/s max) on a DC24V terminal coil. Push force is 3927 N at 0.5 MPa and 6282 N at 0.8 MPa. Although the cylinder body rates to 1.0 MPa, the assembled unit must operate in the 0.15-0.8 MPa valve window.
No, the built-in valve only routes air and is not a load lock. The piston will drift on air loss, and the 29 mm cushions only decelerate near stroke end. To hold a load securely, install an external rod lock or pilot-operated check valve.
