Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100S-08A
2、Enables direct one-to-one pneumatic control without external valve installation.
3、Optimizes spatial efficiency and installation time, ideal for decentralized configurations in large-scale systems.
4、Supports multiple standardized mounting accessories for simplified integration.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SAUF
AirTAC SAUF100X100S-08A Valve-Integrated Cylinder Specifications
- Model: SAUF100X100S-08A
- Type: Double-acting cylinder with integrated 5/2-way solenoid valve
- Bore size: Ø100mm
- Stroke: 100mm (standard) / customizable up to 500mm
- Operating pressure: 0.1–0.9 MPa
- Valve voltage: DC24V (±10%) / AC110V/220V (50/60Hz)
- Port size: PT1/2 (G1/2 optional)
- Cushioning: Adjustable pneumatic cushion
- Seal material: NBR/PU hybrid seals
- Temperature range: -20℃ to 80℃
- Weight: ~8.5kg (with valve)
- Dimensions: 300mm(L) × 120mm(W) × 120mm(H) (at mid-stroke)
- Response time: ≤0.1s (valve switching)
- Protection rating: IP67 (cylinder) / IP65 (valve)
- Lubrication: Pre-lubricated (non-relubrication design)
High-force integrated cylinder-valve unit featuring space-saving design with direct-mounted solenoid valve. The SAUF series combines ISO 15552 cylinder standards with optimized flow paths (12mm orifice valve) for rapid actuation. Anti-vibration mounting brackets and shock-absorbing end caps ensure stable operation in high-cycle applications.
- Heavy-duty clamping systems in injection molding
- Automated palletizing robot end-effectors
- Steel mill conveyor gate controls
- Paper processing machinery actuators
- Electric vehicle battery assembly presses
Installation guidelines:
Mount using M10x1.5 mounting bolts (grade 8.8 or higher). Maintain minimum 50mm
clearance around valve for heat dissipation. Use 5μm filtered dry air with
automatic drain. Lubricate via built-in grease nipple (ISO VG32 recommended)
every 500,000 cycles in continuous operation.
- Max side load: 450N at full extension
- Piston speed: 50–700mm/s (optimal efficiency range)
- Duty cycle: 100% @ 0.5MPa / 80% @ 0.9MPa
| Property | Property Value |
|---|---|
| sku | SAUF100X100S-08A |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Standard Voltage | AC220V |
| Solenoid Valve Model | 4M Series, 31mm Bore, 80mm Stroke, M9W Sensor |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
